Silicone Single Core Cable is a high-performance temperature-resistant cable featuring silicone insulated conductors designed for extreme temperature applications ranging from -60°C to +1800°C. This cable type offers a versatile and economical solution for temperature-sensitive wiring in industrial environments including heating elements, lighting, manufacturing, food processing, cold storage, and refrigeration plants. The cables are available in multiple variants such as SiF, SiF-GL, SiF-HT, SiF-G-Si-HT, and SiHF, each tailored with fine or flexible tinned copper strands, silicone insulation, and optional glass fiber braiding or silicone sheathing for enhanced mechanical and thermal properties. Particularly valued for their flame resistance, minimal smoke emission, and maintenance of circuit integrity during fire, Silicone Single Core Cables are ideal for critical infrastructure in airports, hospitals, and public buildings, ensuring reliable operation of alarms, lighting, and controls under extreme thermal conditions.
Key Features
| Features | Description |
|---|---|
| Temperature Range | -60°C to +1800°C |
| Conductor Material | Fine or flexible tinned copper wire strands, class 5 |
| Insulation Material | High-grade Silicone rubber |
| Variants Available | SiF, SiF-GL, SiF-HT, SiF-G-Si-HT, SiHF |
| Additional Protection | Optional impregnated glass fiber braid and silicone sheath |
| Color Options | Various colors including reddish brown, black, white, and blue |
| Flexibility | Designed for both flexing and fixed installations |
| Fire Resistance | Maintains integrity by forming SiO2 insulation layer in fire conditions |
| Low Smoke Emission | Minimizes smoke and fumes in fire scenarios |
| Applications | Heating elements, lighting, manufacturing, food processing, cold stores, refrigeration, alarm and control circuits |
| Attributes | Description |
|---|---|
| Type | Silicone Single Core Cable |
| Conductor Class | Class 5, fine or flexible tinned copper strands |
| Insulation Thickness | As per standard range for high temperature resistance |
| Sheath Options | Silicone rubber or impregnated glass fiber braid |
| Operating Temperature Range | -60°C to +1800°C |
| Voltage Rating | High voltage insulation available (SiF-HT and variants) |
| Color Coding | Multiple color options for identification |
| Flexibility Rating | Suitable for both flexible and fixed wiring |
| Safety Features | Fire-resistant, low smoke emission, maintains circuit integrity during fire |
| Application Fields | Industrial heating, manufacturing, food processing, cold storage, public infrastructure |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
The cable forms an insulated layer of SiO2 during fire, maintaining circuit integrity with low smoke emission, ensuring uninterrupted operation of alarms.
Yes, the cable's insulation and conductor maintain flexibility and performance at temperatures as low as -60°C, ideal for cold storage and refrigeration applications.
SiF uses fine tinned copper wire strands with silicone insulation for general purposes, whereas SiF-HT includes high voltage silicone insulation suitable for higher voltage applications.
Glass fiber braiding provides additional mechanical protection and thermal resistance, improving durability in extreme environments.
Yes, various colors including reddish brown, black, white, and blue are available to facilitate easy identification and compliance.
