Introducing the High Precision Levelling & Alignment Mounts Series DFL1-S3, specifically engineered to provide robust support and exceptional levelling capabilities for heavy machinery in industrial applications. Constructed from high-grade cast iron, these mounts ensure durability and reliability. The substantial supporting surface enhances stability, while the high levelling adjustment range of 6mm allows for precise alignment, crucial for heavy machinery such as Vertical Turning Lathes (VTL), long bedded CNC machines, large boring machines, and plano millers. A unique feature of the DFL1-S3 mounts is the centrally located slot, which enables easy installation after the grouting bolts have been fixed, saving time and simplifying maintenance. With a maximum load capacity of 12,200 kg and a maximum torque value of 603 N.m, these mounts are designed to meet the demanding needs of modern industrial environments. Available in an appealing green/dark grey finish and packaged in robust boxes, this product is a perfect blend of functionality and durability.
Key Features
| Features | Description |
|---|---|
| Material | High-grade cast iron |
| Load Capacity | 12,200 kg |
| Maximum Torque Value | 603 N.m |
| Adjustment Range | 6 mm |
| Dimensions (L x W x H) | 188 mm x 140 mm x 68.5 mm |
| Weight per mount | 45 kg |
| Suitable for | VTL, long bedded CNC machines, large boring machines, plano millers |
| Color Options | Green/Dark Grey |
| Box Size | 13" x 8" x 7" |
| Delivery Time | 10-12 days |
| Attributes | Description |
|---|---|
| Length | 188 mm |
| Width | 140 mm |
| Height | 68.5 mm |
| Load Capacity | 12,200 kg |
| Max Torque Value | 603 N.m |
| Adjustment Range | 6 mm |
| Weight (per mount) | 45 kg |
| Material | Cast Iron |
| Color | Green/Dark Grey |
| Number of Mounts | 4 |
| Box Size | 13" x 8" x 7" |
| Total Boxes | 2 |
| Delivery Time | 10-12 days |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
The DFL1-S3 mounts are suitable for Vertical Turning Lathes (VTL), long bedded CNC machines, large boring machines, and plano millers.
Each DFL1-S3 mount can support a maximum load of 12,200 kg.
The central slot allows for easy installation after the grouting bolts have been fixed in the foundation, making it time-efficient and simplifying adjustment.
The DFL1-S3 mounts are made from high-grade cast iron, ensuring durability and strength under heavy loads.
The typical delivery time for the DFL1-S3 mounts is 10-12 days.
Brand: dynemech
Country Of Origin: India
The DFL series mounts are made from a high grade casting body. Large supporting surface and high levelling adjustment is available. The slot in the middle allows placement of these mounts after the grouting bolts are fixed in the foundation. Suitable for VTL, long bedded CNC machines, large boring machines, plano miller etc.
Length:188(mm) Width:140(mm) Height:68.5(mm) Load Capacity: 12200 Kg
Max. Torque Value (N.m):603 Adjustment Range(mm):6
4 Nos Weight ( Kg.): 45 kg
Material: Cast Iron
Colour: Green/Dark Grey
4 Nos of Box Size: 13"x8"x7
4 Nos of Boxes: 2
Delivery Time: 10-12 Days
Freight Will Be Extra
The DFL series mounts are made from a high grade casting body. Large supporting surface and high levelling adjustment is available. The slot in the middle allows placement of these mounts after the grouting bolts are fixed in the foundation. Suitable for VTL, long bedded CNC machines, large boring machines, plano miller etc.
Length:188(mm) Width:140(mm) Height:68.5(mm) Load Capacity: 12200 Kg
Max. Torque Value (N.m):603 Adjustment Range(mm):6
4 Nos Weight ( Kg.): 45 kg
Material: Cast Iron
Colour: Green/Dark Grey
4 Nos of Box Size: 13"x8"x7
4 Nos of Boxes: 2
Delivery Time: 10-12 Days
Price-7316
Freight Will Be Extra
