Inclusive of all taxes
The Dynemech Jackup Mounts Series DJM-0 is engineered to provide exceptional isolation solutions for various machinery and mounting conditions. Designed with high load capacity and excellent leveling capabilities, these mounts ensure optimal stability and performance in industrial settings. The non-skid bottom design guarantees secure installation, while the robust construction allows for passive vibration isolation. With adjustable leveling features and a remarkable temperature tolerance of -16°C to 90°C, the DJM-0 series is ideal for diverse operational environments. Whether you're managing heavy machinery or delicate equipment, the Dynemech Jackup Mounts promise reliability, durability, and increased efficiency in your operations. Invest in the DJM-0 for a seamless integration into your operational protocols and experience enhanced performance with reduced vibrations.
Key Features
| Features | Description |
|---|---|
| High Load Capacity | 850Kg/pc to 2500Kg/pc |
| Adjustable Leveling Capability | Up to 18 mm |
| Natural Frequency | 18 Hz |
| Coefficient of Friction | 0.9 |
| Temperature Range | -16°C to 90°C |
| Construction Material | Cast Iron, Rubber |
| Non-Skid Bottom Design | Provides stability and prevents slippage |
| Compact Size | Diameter from 90 mm to 160 mm |
| Attributes | Description |
|---|---|
| Diameter (D) | 90 mm to 160 mm |
| Height (H) | 49 mm |
| Thread Specification (G) | M20x2.5, Thread Length: 38 mm |
| HEX Size (SW) | 46 mm to 62 mm |
| Weight | 1.5 Kg to 5 Kg |
| Price | 1740 |
| Passive Vibration Isolation | Yes |
| Color | Red |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
The maximum load capacity is 2500Kg per unit.
Yes, they can operate in temperatures ranging from -16°C to 90°C.
Yes, these mounts provide excellent passive vibration isolation.
The DJM-0 mounts are made from cast iron and rubber, ensuring durability.
The mounts have adjustable leveling capabilities of up to 18 mm.
Brand: dynemech
Country Of Origin: India
Dynemech Jackup mounts DJM-0 provides isolation solutions for various machines and mounting conditions. The Dynemech Jackup mounts also provides for high machine leveling capabilities. These Jackup mounts provide high load capacity and best level stability. The bottom design provides for non-skid properties for the Jackup mount. The Jackup mount also provide very good passive vibration isolation.
Dia D(mm):- 90mm To 160mm
Height H(mm):-49mm To 49mm
G(mm): M20x2.5 Thread Length:38mm To M20x2.5mm
Thread Length:38mm HEX SW(mm): 46(mm) To 62(mm)
Load Capacity:850Kg/pc To 2500Kg/pc
Levelling Adjustment(mm):18 mm To 18 mm
Natural Frequency Range Hz: 18(Hz) To 18(Hz)
Coeff. of Friction: 0.9 To 0.9
Weight ( Kg.):1.5 Kgs To 5 Kgs
Working Temp Range: -16 to 90
Freight Will Be Extra
Dynemech Jackup mounts DJM-0 provides isolation solutions for various machines and mounting conditions. The Dynemech Jackup mounts also provides for high machine leveling capabilities. These Jackup mounts provide high load capacity and best level stability. The bottom design provides for non-skid properties for the Jackup mount. The Jackup mount also provide very good passive vibration isolation.
Dia D(mm):- 90mm To 160mm
Height H(mm):-49mm To 49mm
G(mm): M20x2.5 Thread
Length:38mm To M20x2.5mm
Thread Length:38mm HEX SW(mm): 46(mm) To 62(mm)
Load Capacity:850Kg/pc To 2500Kg/pc
Levelling Adjustment(mm):18 mm To 18 mm
Natural Frequency Range Hz: 18(Hz) To 18(Hz)
Coeff. of Friction: 0.9 To 0.9 Weight ( Kg.):1.5 Kgs To 5 Kgs
Working Temp Range: -16 to 90
Material : Cast Iron, Rubber
Colour: Red
Price-2054
Freight Will Be Extra
