The Dynemech Anti-Vibration Anchor Mats, Series Da1, are engineered to provide superior vibration damping and insulation in industrial settings. Constructed from high-grade synthetic composite materials, these mats are expertly designed to resist a wide variety of shop floor contaminants including water, oils, lubricating oils, and fuels. With precise specifications allowing for direct placement under machinery according to weight and mounting positions, these insulation mats excel in preserving the longevity of both equipment and flooring. They are capable of withstanding loads between 2 to 18 kg while maintaining dimensional stability and performance due to their defined stress values. The material composition includes Nitrile Rubber, Cork, Synthetic Fiber, and other high-grade compounds, making them ideal for diverse operations. The mats measure 500mm x 500mm x 2mm, offer a natural frequency range of 30-70 Hz, a coefficient of friction of 0.8, and operate effectively within a temperature range of -20°C to +70°C. The durability and resistance to deformation ensure that these mats remain a reliable choice for any business seeking to mitigate vibrations and enhance workplace safety and efficiency.
Key Features
| Features | Description |
|---|---|
| Material Composition | Nitrile Rubber, Cork, Synthetic Fiber and other high-grade compounds |
| Size | 500mm x 500mm x 2mm |
| Load Capacity | 2 to 18 kg |
| Natural Frequency | 30-70 Hz |
| Coefficient of Friction | 0.8 |
| Shore A Hardness | 40-45 |
| Working Temperature Range | -20°C to +70°C |
| Weight | 2 kg |
| Color Options | Green, Grey, Black |
| Application | Anti-Skid Plate for machinery |
| Attributes | Description |
|---|---|
| Material | High-grade synthetic composite |
| Thickness | 2 mm |
| Applications | Machinery installation and vibration isolation |
| Resistance | Water, oils, lubricating oils, fuels |
| Deformation Resistance | Maintain shape under specified load |
| Industrial Applications | Suitable for various shop floor environments |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
The Da1 Insulation Plate can support machine weights ranging from 2 to 18 kg.
The Dynemech Da1 Mats are made from Nitrile Rubber, Cork, Synthetic Fiber, and other high-grade compounds.
Yes, the mat is resistant to water, oils, lubricating oils, and fuels used within industrial environments.
The working temperature range for these mats is between -20°C and +70°C.
The coefficient of friction for the Da1 Insulation Mats is 0.8.
Brand: dynemech
Country Of Origin: India
Dynemech Anti-Vibration Da1 Insulation Sheet is made from high grade synthetic composite material. This sheet is resistant to water,
oils, lubricating oils, fuels etc. used in the shop floor. This sheet has defined stress value and can be placed directly under the machine as
per the weight of the machine and no. of mounting positions. This plate will not deform plastically, if the weight of machine does not
exceed maximum load value of this Insulation plate.
Application: Anti-Skid Plate.
Size :500x500x2mm
Load Capacity (Kg.):02 to 18
Natural Frequency (Hz):30-70
Thickness (mm):2
Coeff. of Friction:0.8
Shore A Hardness:40-45
Working Temp Range °C:-20 to +70
Weight ( Kg.):2
Material: Nitrile Rubber, Cork, Synthetic Fibre and Other High Gread Compounds.
Colour:Green, Grey, Black
Note- Freight Charges will be excluded.
Dynemech Anti-Vibration Da1 Insulation Sheet is made from high grade synthetic composite material. This sheet is resistant to water,
oils, lubricating oils, fuels etc. used in the shop floor. This sheet has defined stress value and can be placed directly under the machine as
per the weight of the machine and no. of mounting positions. This plate will not deform plastically, if the weight of machine does not
exceed maximum load value of this Insulation plate.
Size :500x500x2mm
Load Capacity (Kg.):02 to 18
Natural Frequency (Hz):30-70
Thickness (mm):2
Coeff. of Friction:0.8
Shore A Hardness:40-45
Working Temp Range °C:-20 to +70
Weight ( Kg.):2
Material: Nitrile Rubber, Cork, Synthetic Fibre and Other High Gread Compounds.
Colour:Green, Grey, Black
Note- Freight Charges will be excluded.
