Ribbed Screen Agriculture Pipe

Brand: finolex

Inclusive of all taxes

The Ribbed Screen Agriculture Pipe by Finolex is a purpose-built PVC-U borewell pipe designed for reliable groundwater extraction in agriculture and water supply applications. Manufactured from a special PVC-U compound, this ribbed screen pipe is engineered to perform in demanding water conditions, including hard, salty, sandy, and chemically aggressive water. It is specifically developed to help deliver clean and clear water from bore wells across shallow, medium, and deep installations. This product line includes Ribbed Screen blue pipes (RMS) conforming to IS: 12818, making it suitable for medium well screen applications, particularly for well depths between 80 and 250 meters. The ribbed design improves screen performance in borewell environments by supporting efficient water intake while helping reduce the entry of sand and unwanted particles, making it a dependable choice for agricultural borewell systems and groundwater extraction projects. Available in multiple nominal diameters, including 100 mm (4"), 125 mm (5"), 150 mm (6"), and 200 mm (8"), the pipe range offers standardized dimensions and wall thicknesses for diverse borewell requirements. The product includes different material codes and standard pipe lengths to suit installation needs. With its robust PVC-U construction and IS-compliant design, the Ribbed Screen Agriculture Pipe is a strong choice for contractors, borewell installers, agriculture infrastructure suppliers, and water management projects seeking durable and efficient screen pipes for borewell use.

Key Features

Features Description
Product Type PVC-U ribbed screen pipe for borewell and agriculture water extraction
Water Compatibility Suitable for hard, salty, sandy, and chemically aggressive water
Standard Compliance Conforms to IS: 12818
Application Depth Designed for medium well applications with well depth between 80 and 250 meters
Screen Design Ribbed screen structure supports borewell water intake while helping reduce sand ingress
Available Sizes Offered in 4", 5", 6", and 8" nominal diameters
Attributes Description
Brand Finolex
Product Name Ribbed Screen Agriculture Pipe
Material PVC-U compound
Product Type Ribbed screen pipe / borewell screen pipe
Standard IS: 12818
Application Borewell water extraction for agriculture and water supply
Water Type Hard, salty, sandy, and chemically aggressive water
Well Depth Range 80 to 250 meters
Slot Width 0.2 mm
Nominal Diameter Options 100 mm (4"), 125 mm (5"), 150 mm (6"), 200 mm (8")
Available Lengths Standard pipe lengths vary by size and material code
Color Blue

*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.

Be the first to write a review

It is manufactured from a special PVC-U compound and designed as a ribbed screen pipe to support water intake while helping manage hard, salty, sandy, and chemically aggressive water conditions.

This medium well screen range is designed for borewell depths between 80 and 250 meters.

Yes, the ribbed screen blue pipes (RMS) conform to IS: 12818.

The available nominal diameters include 100 mm (4"), 125 mm (5"), 150 mm (6"), and 200 mm (8").

The RS ribbed screen pipe variant is listed with a slot width of 0.2 mm.

  • Incorporation Type

  • GST

  • GST Registration Date

  • Number of Employees

  • Import Export Code (IEC)

  • Year of Establishment

  • Nature of Business

  • GlobalLinker Member Since

Brand: finolex

Country Of Origin: India

Finolex offers a wide range of casing and ribbed screen pipes which are manufactured using a special PVC-U compound. This makes them ideal for transportation of hard, salty, sandy, or chemically aggressive water. This range of PVC-U plain casing and ribbed screen pipes are specially designed to ensure clean, clear water from bore well, whether shallow, medium or deep. Finolex offers a wide range of Ribbed Screen blue pipes (RMS). This range is manufactured conforming to IS: 12818 caters to the varied requirements of bore-wells. These are used in different way for water extraction

Dimensions of Screen Pipes with Ribs

DIMENSIONS OF MEDIUM WELL SCREEN  (RMS) PIPES WITH RIBS - CONFORMING TO  IS: 12818
For well depth between 80 - 250 meters.
Nominal Diameter (DN) Mean Outside Diameter of Pipe (mm) Outside Diameter of pipe at any point (mm) Mean Outside diameter over connection
(mm)
Wall Thickness ‘S’ (mm) Material
Code
Std.
Pipe Length
mm inch Min Max. Min Max. max Min. Max   meter
100 4" 117.0 117.3 116.8 117.4 124 5.0 5.7 3064 3
125 5" 144.0 144.4 143.7 144.5 154 6.5 7.3 3065 3
150 6" 169.0 169.4 168.6 169.6 182 7.5 8.5 3066 2.9
150 6" 169.0 169.4 168.6 169.6 182 7.5 8.5 3067 3
200 8" 229.0 229.5 228.5 229.8 247 10.0 11.2 3068 2.9
200 8" 229.0 229.5 228.5 229.8 247 10.0 11.2 3069 3

DIMENSIONS OF 'RS' - RIBBED SCREEN PIPES (SLOTTED) -CONFORMING TO IS: 12818
Slot width :- 0.2 mm
Nominal Diameter (DN) Mean Outside Diameter of Pipe (mm) Outside Diameter of pipe at any point    (mm) Mean Outside diameter over connection
(mm)
Wall Thickness ‘S’ (mm) Material
Code
Std.
Pipe Length
mm inch Min Max. Min Max. max Min. Max
