The SMW Multi Pot Sample Yarn Dyeing Machine is a specialized laboratory equipment designed for simultaneous dyeing of yarn samples in multiple pots ranging from 2, 4, 6 to 8 units. Each pot operates independently with its own pump and controller, allowing for diverse dyeing recipes to be tested under controlled conditions. This capability significantly accelerates the process of recipe standardization, reduces trial and error during bulk production, and optimizes resource utilization. Suitable for a wide range of fibers including Polyester, Cotton, Viscose, Nylon, Acrylic, Texturized fibers, Silk, and Wool, it supports various yarn forms such as Cones, Tapes, Narrow Fabrics, Zippers, Hanks, Ribbons, Tops, and Loose Fibers. Each pot can process batches from 100 gms to 1.5 kg and functions at a maximum temperature of 150°C and pressure of 6 kg, featuring a stainless steel SS316 construction for durability and corrosion resistance. The machine incorporates low and high heating rates (2°C/min and 1°C/min respectively), water cooling systems, and comes with a fully automatic panel board for precise operation, making it an essential tool for textile laboratories focused on developing and replicating dyeing processes accurately for bulk manufacturing.
Key Features
| Features | Description |
|---|---|
| Number of Pots | 2, 4, 6, or 8 pots coupled together |
| Batch Capacity per Pot | 100 grams to 1.5 kilograms |
| Independent Operation | Each pot has separate pump and controller |
| Fiber Compatibility | Polyester, Cotton, Viscose, Nylon, Acrylic, Texturized, Silk, Wool |
| Yarn Forms Supported | Cones, Tape, Narrow Fabrics, Zipper, Hanks, Ribbons, Tops, Loose Fiber |
| Max Working Temperature | 150°C |
| Max Working Pressure | 6 kg/cm² |
| Material of Construction | Stainless Steel 316 (SS316) |
| Heating Rate | Low temperature: 2°C/min, High temperature: 1°C/min |
| Cooling System | Water cooling system |
| Automation | Fully automatic panel board |
| Application | Simultaneous sampling and dyeing of multiple yarns with reproducibility to bulk production |
| Attributes | Description |
|---|---|
| Type of Fibers/Fabric | Silk, Polyester, Light weight cotton, Wool, Viscose, Nylon, Acrylic, Texturized fibers |
| Maximum Working Temperature | 150°C |
| Maximum Working Pressure | 6 kg/cm² |
| Heating Rate | Low temperature 2°C/min, High temperature 1°C/min |
| Cooling Rate | Water cooling system |
| Material of Construction | Stainless Steel 316 (SS316) |
| Batch Capacity per Pot | 100 gms to 1.5 kgs |
| Control System | Fully automatic panel board |
| Number of Pots Available | 2, 4, 6, 8 |
| Application | Laboratory-level simultaneous dyeing of multiple yarn samples |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
Yes, each pot has its own pump and controller, allowing it to run independently with different dye recipes simultaneously.
Each pot can handle batch sizes ranging from 100 grams up to 1.5 kilograms as per the requirements.
Yes, it supports a wide range of fibers including synthetic fibers such as polyester, nylon, acrylic, and texturized yarns.
The machine offers precise temperature, pressure control, and automation, enabling exact duplication of dyeing conditions, which facilitates reproducibility from laboratory scale to bulk production.
It uses a water cooling system to manage cooling rates effectively after the dyeing process.
Yes, it is suitable for natural fibers including silk and wool along with various other fiber types.
Yes, it supports both low temperature heating rates at 2°C/min and high temperature heating rates at 1°C/min for precise temperature ramp-up.
Country Of Origin: India
SMW Multi Pot Sample Dyeing Machine is ideal to run 2, 4, 6, & 8 Pots coupled to each other, dyeing yarns of same colour or running individually to facilitate dyeing yarn of different colours simultaneously. This is very useful for standardizing the recipes of dyeing before batches are taken in bulk. This avoids trial and error methods, hence saves time and resources utilized. Each pot has a range from 100 gms. To 1.5 kg. per batch as per the requirement. The apparatus allows sampling trails in laboratory. Each vessel can be charged with different type of materials. Each kier has its own pump and controller. Main feature of this machine is a perfect reproducibility from laboratory to bulk production. The machines are available with different levels of automations. The machine is suitable for dyeing of Polyester, Cotton, Viscose, Nylon, Acrylic, Texturized, Silk, Wool, etc. in various forms like Cone, Tape, Narrow Fabrics, Zipper, Hanks, Ribbons, Tops & Loose Fiber.
Multi Pot Sample Dyeing MachineTechnical Specification :
Multi Pot Sample Dyeing MachineTechnical Specification :
Type of Fibers / Fabric : Silk, Polyester, Light weight cotton, Wool etc.
Maximum working temperature : 150°C
Maximum working pressure : 6 kg
Heating Rate : Low temperature 2°C / High temperature 1°C
Cooling Rate : Water cooling system
MOC : SS316
Capacity : to 300gms
Panel Board : Fully automatic
Application : For sampling number of yarns seperately in one machine
