The MILD STEEL PVC RUNGS STMS027A is a premium-grade ladder rung designed with durability and safety as core priorities. Manufactured in compliance with EN 13101:2002 standards, this product features a solid Ø12 mm mild steel rod (Grade SAE 1018) core fully encapsulated with a minimum 2.5 mm thick layer of polypropylene (PP) for enhanced corrosion resistance. The encapsulation process coupled with a UV stabilized master batch ensures exceptional longevity and protection against environmental degradation. With precise dowel spacing of 145 ± 1 mm and a standard rung width of 165 mm, these rungs offer ergonomic leg lengths ranging from 240 to 245 mm and grip length of 110 ± 1 mm, providing secure footing and comfort. Available in standard colors including Orange, Yellow, Black, and Blue, the rungs weigh approximately 0.71 Kg each. Engineered for demanding industrial and commercial environments, these rungs withstand pull-out loads of 245 Kg, compression loads of 484 Kg, and maximum loads up to 582 Kg (all approximate). Additional safety features include non-slip threads and lateral slipping protection, ensuring a firm grip and safe use in elevated working conditions without any sharp edges. Perfect for integration in fixed ladders and maintenance platforms, the STMS027A rungs deliver reliability, strength, and user safety in one corrosion-resistant package.
Key Features
| Features | Description |
|---|---|
| Core Material | Ø12 mm Mild Steel Rod, Grade SAE 1018 |
| Encapsulation | Minimum 2.5 mm Thick Polypropylene (PP) |
| Standard Compliance | EN 13101:2002 |
| Dowel Distance | 145 ± 1 mm |
| Rung Width | 165 mm |
| Leg Length | 240-245 mm |
| Grip Length | 110 ± 1 mm |
| Standard Colors | Orange, Yellow, Black, Blue |
| Product Weight | 0.71 Kg |
| Pull-Out Load Capacity | 245 Kg (approx.) |
| Compression Load Capacity | 484 Kg (approx.) |
| Maximum Load Capacity | 582 Kg (approx.) |
| UV Stability | UV Stabilized Master Batch for Long-Term Outdoor Use |
| Safety Features | Non-Slip Threads, Lateral Slipping Protection, No Sharp Edges |
| Corrosion Resistance | Full Polypropylene Encapsulation Ensures High Resistance |
| Attributes | Description |
|---|---|
| Standard Description | EN 13101:2002 |
| Core Material | Ø12 mm Mild Steel Rod, Grade SAE 1018 |
| Encapsulation Material | Polypropylene (PP), Min 2.5 mm Thickness |
| Dowel Distance | 145 ± 1 mm |
| Width | 165 mm |
| Leg Length | 240-245 mm |
| Grip Length | 110 ± 1 mm |
| Product Weight | 0.71 Kg |
| Pull-Out Load | 245 Kg (approx.) |
| Compression Load | 484 Kg (approx.) |
| Max Load | 582 Kg (approx.) |
| Available Colors | Orange, Yellow, Black, Blue |
| UV Resistance | UV Stabilized Master Batch |
| Additional Features | Non-Slip Threads, Lateral Slipping Protection, No Sharp Edges |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
The polypropylene encapsulation, with a minimum thickness of 2.5 mm, offers superior corrosion resistance protecting the mild steel core from rust and environmental damage. This encapsulation also delivers UV stability for prolonged outdoor usage and enhances user safety by covering any sharp edges.
STMS027A ladder rungs incorporate non-slip threads on the surface and include lateral slipping protection, ensuring firm footing and increased safety for users, especially under wet or oily conditions.
Yes, the STMS027A rungs possess a pull-out load capacity of approximately 245 Kg, compression load capacity of about 484 Kg, and a maximum load capacity near 582 Kg, making them robust and suitable for heavy-duty industrial ladder applications.
Absolutely. The rungs feature a UV stabilized master batch combined with polypropylene encapsulation that protects against weathering and UV radiation, making them highly suitable for outdoor environments.
The STMS027A is offered in multiple standard colors including Orange, Yellow, Black, and Blue, allowing buyers to select rungs that best fit their industrial safety color codes or aesthetic preferences.
Country Of Origin: India
What sets us apart from our competitors is the wide range of product features that only we can guarantee. The following are some of the factors that set our products apart.
We manufacture Manhole steps as per the European Standard- Steps for underground man entry chambers i.e., EN13101:2002.
Plastic encapsulation for protection from all types of corrosion.
Superior resistance exceeding international standards.
Spark proof and polymer covered.
High impact resistance.
Extremely easy to install and cost-effective.
No sharp edges or corners and anti-slip surfaces.
The steps conform to all quality parameters. Test Certificate according to Applicable European Standard EN13101:2002
Unique designed with a step width of 165 mm and length of 245 mm
Out of 245 mm , 110 mm can be grouted inside wall
TECHNICAL DATA
Standard Description : EN 13101:2002
Core Material : Ø12 mm MILD STEEL ROD Grade-SAE 1018 -
Encapsulation POLYPROPYLENE (PP) Min 2.5 mm at any point. mm
Dowel Distance : 145 ± 1 mm
Width : 165 mm
Leg Length 240-245 mm
Grip Length 110 ± 1 mm
Standard Color Orange,Yellow,Black,Blue
Product Weight : 0.71 Kg *
Pull Out Load 245 Kg *
Compression Load 484 Kg *
Max. Load 582 Kg *
( * approx.)
KEY FEATURES
Full Encapsulation for high corrosion resistance.
UV Stablized Master Batch.
High Impact Resistance
Non Slip Threads
Lateral Slipping Protection.
No sharp edges.
