The MILD STEEL PVC ENCAPSULATED RUNGS STMS027B is a high-quality manhole step designed and manufactured to meet the stringent requirements of the European Standard EN13101:2002 for underground man entry chambers. These rungs feature a core made of 12 mm diameter mild steel SAE 1018 rod, fully encapsulated in a minimum 2.5 mm thick polypropylene (PP) layer, providing exceptional protection against corrosion and environmental damage. With UV stabilized master batch incorporated into the polymer encapsulation, these rungs resist sun damage, maintaining durability and color integrity over time. The unique design offers a wide step surface of 165 mm by 215 mm, with 80 mm intended to be embedded securely inside masonry, ensuring a sturdy installation. The surface includes non-slip threads and lateral slipping protection for enhanced safety, while the smooth rounded edges eliminate hazards commonly associated with traditional rungs. Offering a pull-out load capacity of approximately 248 kg, compression load of 479 kg, and maximum load around 586 kg, these steps combine safety, performance, and longevity. Available in standard colors including orange, yellow, black, and blue, the STMS027B model is a superior solution for underground infrastructure access requiring reliable, cost-effective, and easy-to-install manhole steps that exceed international corrosion resistance standards.
Key Features
| Features | Description |
|---|---|
| European Standard Compliance | Manufactured as per EN13101:2002 for underground man entry chambers |
| Core Material | Ø12 mm mild steel rod-grade SAE 1018 |
| Encapsulation Material | Polypropylene (PP) with minimum 2.5 mm thickness |
| Corrosion Resistance | Full plastic encapsulation provides superior corrosion protection |
| Impact Resistance | High impact resistance with spark proof and polymer covering |
| Step Dimensions | Step width 165 mm, length 215 mm with 80 mm embedment length |
| Load Capacity | Pull-out load approx. 248 kg, compression load approx. 479 kg, max load approx. 586 kg |
| Safety Features | Non-slip threads, lateral slipping protection, no sharp edges |
| UV Stability | UV stabilized master batch incorporated |
| Color Options | Available in Orange, Yellow, Black, and Blue |
| Attributes | Description |
|---|---|
| Standard Description | EN13101:2002 - Steps for underground man entry chambers |
| Core Material | 12 mm diameter mild steel SAE 1018 rod |
| Encapsulation Thickness | Minimum 2.5 mm polypropylene |
| Dowel Distance | 145 ± 1 mm |
| Step Width | 165 mm |
| Step Length | 210-215 mm |
| Grip Length (Suggested Embedment) | 80 ± 1 mm |
| Standard Colors | Orange, Yellow, Black, Blue |
| Product Weight | 0.65 kg (approximate) |
| Pull-out Load Capacity | 248 kg (approximate) |
| Compression Load Capacity | 479 kg (approximate) |
| Maximum Load Capacity | 586 kg (approximate) |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
The STMS027B features full encapsulation of the mild steel core with a minimum 2.5 mm thick polypropylene coating that provides superior resistance to all types of corrosion including chemical and environmental exposure, exceeding international standards.
It is manufactured as per the European Standard EN13101:2002, ensuring it meets strict safety and quality parameters designed specifically for steps in underground man entry chambers, with features like non-slip threads and no sharp edges.
Out of the total 215 mm step length, an 80 mm portion is designed to be grouted inside the wall or masonry to ensure secure anchorage.
Yes, these rungs include a UV stabilized master batch in the polypropylene encapsulation, providing effective resistance to UV degradation and maintaining durability and color stability.
They offer a pull-out load capacity of approximately 248 kg, compression load capacity of approx. 479 kg, and a maximum load capacity near 586 kg, suitable for heavy-duty use.
They are available in standard colors including orange, yellow, black, and blue for visual identification and safety.
Country Of Origin: India
What sets us apart from our competitors is the wide range of product features that only we can guarantee. The following are some of the factors that set our products apart.
We manufacture Manhole steps as per the European Standard- Steps for underground man entry chambers i.e., EN13101:2002.
Plastic encapsulation for protection from all types of corrosion.
Superior resistance exceeding international standards.
Spark proof and polymer covered.
High impact resistance.
Extremely easy to install and cost-effective.
No sharp edges or corners and anti-slip surfaces.
The steps conform to all quality parameters. Test Certificate according to Applicable European Standard EN13101:2002
Unique designed with a step width of 165 mm and length of 215 mm
Out of 215 mm , 80 mm can be grouted inside wall
TECHNICAL DATA
Standard Description : EN 13101:2002 -
Core Material Ø12 mm MILD STEEL ROD Grade-SAE 1018 -
Encapsulation POLYPROPYLENE (PP) Min 2.5 mm at any point. mm
Dowel Distance : 145 ± 1 mm
Width : 165 m
Leg Length : 210-215 mm
Grip Length : 80 ± 1 mm
Standard Color Orange,Yellow,Black,Blue
Product Weight : 0.65 * kg
Pull Out Load : 248 * kg
Compression Load : 479 * kg
Max. Load : 586 * kg
( * approx.)
KEY FEATURES
Full Encapsulation for high corrosion resistance.
UV Stablized Master Batch.
High Impact Resistance
Non Slip Threads
Lateral Slipping Protection.
No sharp edges.
