The Tie-Rod Cylinder with Forged Mounting is engineered for the most demanding industrial environments requiring robust and reliable hydraulic actuation. Featuring high-tensile tie rods that securely hold the end caps, and precision-machined forged mounting ends, this hydraulic cylinder excels in strength, durability, and resistance to mechanical stresses such as shock loads and vibrations. Its hardened, chrome-plated piston rods and ST52 honed precision tubes deliver outstanding wear resistance and longevity, even under pressures up to 300 bar. Available in single or double-acting configurations with versatile mounting options including forged clevis, trunnion, and flange mounts, this cylinder caters perfectly to applications in hydraulic presses, mining equipment, steel plants, injection molding, and heavy machinery. The forged mounts outperform traditional welded or cast ends by offering crack resistance and enhanced safety, ensuring continuous operation with minimal maintenance in harsh environments. Premium seals from trusted brands like Hallite or Parker further enhance the cylinder's reliability by preventing leaks and contamination. This tie-rod hydraulic cylinder is the ideal solution when high mechanical strength, operational safety, and long service life are imperative.
Key Features
| Features | Description |
|---|---|
| Mounting Type | Forged clevis, trunnion, and flange mounts |
| Cylinder Design | Tie-rod with high-tensile rods holding end caps |
| Piston Rod | Hardened and chrome-plated for wear resistance |
| Tube Material | ST52 honed tube for precision and durability |
| Seal Type | Premium Hallite or Parker seals for leak prevention |
| Operating Pressure | Up to 300 bar working pressure |
| Action Type | Available in single and double acting variants |
| Construction Advantage | Forged mounting ends are crack-resistant and shock load tolerant |
| Maintenance | Easy to service due to robust tie-rod structure |
| Applications | Hydraulic presses, steel plants, mining, injection molding, heavy machinery |
| Attributes | Description |
|---|---|
| Material of End Caps | Forged steel |
| Tie Rod Material | High tensile steel |
| Seal Brand Options | Hallite, Parker |
| Available Bore Sizes | Multiple customizable bore diameters |
| Stroke Length | Customizable according to application |
| Mounting Styles | Forged clevis, trunnion, flange |
| Piston Rod Diameter | Varies per order specifications |
| Cylinder Body Material | ST52 steel tube honed precision finish |
| Operating Temperature Range | -20°C to +80°C (typical, application dependent) |
| Cylinders Available | Single acting, double acting |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
Forged mounting ends offer superior mechanical strength and crack resistance compared to welded or cast ends. This construction enhances the cylinder's ability to withstand higher shock loads and harsh industrial conditions, resulting in increased operational safety and longer service life.
The cylinder is rated for operating pressures up to 300 bar. Using it above this pressure is not recommended as it may compromise safety and performance. Custom engineering evaluations are necessary if operation beyond 300 bar pressure is required.
The tie-rod structure allows easy disassembly and servicing since the rods hold the end caps securely yet can be removed for inspection or repairs. This design simplifies maintenance and reduces downtime in industrial settings.
Yes, the cylinder can be supplied with a wide range of bore diameters and stroke lengths tailored to specific application requirements, ensuring optimal performance and integration.
Premium seals from Hallite and Parker are used to prevent hydraulic fluid leaks and protect against contamination. These seals are engineered for durability and consistent performance under high pressures and varied temperature ranges, enhancing the operational reliability of the cylinder.
Country Of Origin: India
The Tie-Rod Hydraulic Cylinder with Forged Mounting is a robust linear actuator designed for high-pressure and heavy-duty applications. Its structure uses high-tensile tie rods to hold the end caps together, while the forged mounting ends provide superior strength, durability, and resistance to mechanical stress. Ideal for use in industrial automation, construction, and heavy machinery where dependability and long service life are critical.
This cylinder features a rigid tie-rod design that is easy to service and maintain, combined with precision-machined forged mounts that offer significant advantages over welded or cast alternatives. The forged ends are crack-resistant and capable of withstanding higher shock loads, making them especially suited for rugged environments. Constructed using hardened and chrome-plated piston rods, ST52 honed tubes, and premium seals (such as Hallite or Parker), the cylinder is designed to operate reliably under working pressures up to 300 bar. It is available in both single and double acting versions, with a wide range of bore and stroke sizes, and customizable mounting styles such as forged clevis, trunnion, and flange mounts. These cylinders are ideal for hydraulic presses, steel plants, mining equipment, injection molding machines, and any system where high strength and low maintenance are required. The forged construction not only increases mechanical strength but also enhances safety and operational life in demanding industrial applications.
