The Medium Voltage Switchboard Up to 33kV with Draw-Out Breakers is a high-performance, IEC 62271-200:2011 compliant switchgear panel designed for medium voltage power distribution in industrial and utility applications. Engineered to provide control and protection of potential transformers, capacitor feeders, and motor feeders, this MV switchboard supports operational voltage classes of 12 kV and 36 kV with current ratings ranging from 630A to 3150A. Featuring draw-out type breakers and PTs, it ensures safe and efficient maintenance by enabling isolated inspection and replacement without system disruption. Its SCADA-ready design integrates seamlessly with centralized supervisory control systems, enhancing remote monitoring and operational transparency. The panel includes a clear mimic front display for real-time operational status indication and offers flexible cable entry options from the top or bottom to accommodate diverse site installation preferences. Constructed with robust aluminium or copper busbars for optimal conductivity, and enclosed within an IP5X rated dust-resistant casing finished in Siemens Grey RAL 7032, this switchboard is compact and lightweight, ideal for installations with limited space and stringent handling demands. Control circuits support multiple voltage options (24VDC, 110VDC, and 220VDC), and it delivers reliable operation with a maximum temperature rise of 40°C over an ambient of 45°C, aligning with demanding industrial power distribution standards.
Key Features
| Features | Description |
|---|---|
| Voltage Rating | Up to 33kV (12 kV & 36 kV class) |
| Current Ratings | 630A, 800A, 1250A, 2000A, 2500A, 3150A |
| Breaker Type | Draw-out breakers enabling safe maintenance and replacement |
| Standard Compliance | IEC 62271-200:2011 |
| SCADA Compatibility | Supports centralized monitoring and supervisory control |
| Enclosure Protection | IP5X rated for dust protection |
| Busbar Material Options | Aluminium or Copper |
| Cable Entry Options | Top or bottom entry for flexible site installation |
| Control Voltage Options | 24VDC, 110VDC, 220VDC |
| Panel Color Finish | Siemens Grey RAL 7032 with 80-120 micron coating thickness |
| Attributes | Description |
|---|---|
| Voltage Classes | 12 kV and 36 kV |
| Operational Current Range | 630A to 3150A |
| Frequency | 3-phase, 50 Hz |
| Breaker Configuration | Draw-out type breakers and PTs |
| Degree of Protection | IP5X dust ingress protection |
| Busbar Material | Aluminium or copper options |
| Control Circuit Voltage | 24VDC, 110VDC, 220VDC |
| Color Standard | Siemens Grey RAL 7032 |
| Coating Thickness | 80–120 microns |
| Maximum Temperature Rise | 40°C over ambient 45°C |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
Draw-out breakers allow safe withdrawal and isolation for inspection, testing, and replacement without disrupting the entire electrical system, enhancing maintenance safety and operational uptime.
The switchboard is designed with SCADA-ready interfaces enabling seamless integration with supervisory control systems for real-time monitoring, control, and coordination across substations or industrial plants.
Yes, busbar material can be specified as either aluminium or copper to meet different conductivity requirements and project standards.
The enclosure carries an IP5X rating, ensuring strong protection against dust ingress, suitable for typical switchboard room environments.
Control circuits support 24VDC, 110VDC, and 220VDC configurations, providing flexibility based on site electrical system design.
Brand: hartik
Country Of Origin: India
Medium Voltage Switchboard up to 33kV for B2B power distribution, built for control and protection of potential transformers, capacitor feeders, and motor feeders. Draw-out breaker and PT construction supports safer maintenance routines, while IEC 62271-200:2011 compliance and SCADA monitoring suit structured utility and industrial switchgear procurement.
Medium Voltage Switchboard Overview
Medium Voltage Switchboard up to 33kV supports structured distribution and protection duties in utility and industrial electrical systems. The assembly covers control and protection for potential transformers, capacitor feeders, and motor feeders, with a compact, lightweight build suited to panel rooms where footprint and handling matter.
Standards and Operational Ratings
IEC 62271-200:2011 compliance aligns the switchboard with recognized safety and performance benchmarks for medium voltage switchgear. Operational voltage is specified as 12 kV and 36 kV classes, with current ratings from 630A to 3150A, enabling alignment with varied feeder loads and network configurations.
Draw-Out Construction for Service Access
Draw-out type breakers and PTs support controlled withdrawal for inspection, testing, and replacement procedures. This configuration helps maintenance teams manage servicing without unnecessary disruption, while maintaining structured safety practices expected in medium voltage panel environments.
Monitoring and Interface Integration
SCADA-ready centralized monitoring supports integration into supervisory control systems for coordinated substation or plant-level oversight. A front-facing mimic display provides clear operational visibility, supporting routine switching operations and status verification within controlled electrical rooms.
Mechanical Build and Configuration Details
Aluminium or copper busbar options allow specification alignment based on conductivity and project standards. The enclosure carries an IP5X protection rating with 80–120 micron coating thickness and Siemens Grey RAL 7032 finish, with top or bottom cable entry and control voltages of 24VDC, 110VDC, or 220VDC.
