The EtchON Dot Pin Marking Machine PC Based with Rotary Fixture (Domestic Series) is a versatile and compact industrial marking solution designed for precise and permanent engraving on a variety of materials, especially small and lightweight metal and plastic workpieces. Featuring a 100x100 mm working area and a 300 mm working height, this PC-based dot pin marking machine supports customization tailored to specific customer requirements. Equipped with a rotary fixture, it allows for 360-degree marking on cylindrical or round components, making it an ideal choice for nameplate applications, automobile parts, cylinder markings, machined and cast parts, as well as bearing identification. The machine integrates a column-mounted PC controller compatible with Windows 98, XP, and Windows 7 (32-bit), and supports various marking styles including linear, angular, radial, inverted, and mirror engraving. It also accepts vector graphic formats such as .PLT, .SLG, and .DWG from software like AutoCAD and CorelDRAW. Constructed with a modular aluminum casing, the machine ensures effective heat dissipation and durability. Its marking head uses standard components to guarantee long-lasting, maintenance-free operation. The EtchON DPM303D is perfect for businesses requiring high-precision and customizable dot pin marking technology for both metal and non-metal parts in industrial environments.
Key Features
| Features | Description |
|---|---|
| Working Area | 100 x 100 mm |
| Working Height | 300 mm (customizable) |
| Marking Type | PC Based Dot Pin Marking with Rotary Fixture |
| Material Compatibility | Suitable for light metal and plastic workpieces |
| Marking Styles | Linear, Angular, Radial, Inverted, Mirror |
| Graphic Formats Supported | .PLT, .SLG, .DWG (AutoCAD and CorelDRAW) |
| Operating System Compatibility | Windows 98, XP, Windows 7 (32-bit) |
| Controller Type | Column Mounted PC Based Controller |
| Marking Content | Logos, Alphanumeric Characters, Dates, Serial Numbers, Graphs |
| Construction | Modular Aluminum Casing with Fast Heat Dissipation |
| Attributes | Description |
|---|---|
| Model | DPM303D |
| Machine Type | Dot Pin Marking Machine |
| Fixture Type | Rotary Fixture Included |
| Marking Area Dimensions | 100 mm x 100 mm |
| Maximum Workpiece Height | 300 mm (customizable) |
| Material Compatibility | Light metals, plastics |
| Marking Methods | Line and Dot Engraving |
| Supported Fonts | Multiple font support |
| Marking Capability | Logos, Characters, Alphanumeric, Dates, Serial Numbers, Graphs |
| Software Compatibility | AutoCAD, CorelDRAW Graphic Files |
| Operating Systems Supported | Windows 98, XP, Windows 7 (32-bit) |
| Machine Body Material | Modular Aluminium Casing |
| Control System | PC Based with Column Mount |
| Maintenance | Lifelong maintenance-free design |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
Yes, the included rotary fixture allows the machine to mark cylindrical and round components efficiently by rotating the workpiece during the marking process.
Yes, the machine's 300 mm working height can be customized based on specific customer requirements to accommodate larger workpieces.
The EtchON DPM303D supports .PLT, .SLG, and .DWG graphic files from AutoCAD and CorelDRAW software, enabling flexible design import.
The machine supports Windows 98, Windows XP, and Windows 7 (32-bit) operating systems for its controller software.
Yes, the EtchON DPM303D is suitable for marking on both light metal and plastic workpieces, making it versatile for various industrial applications.
It supports multiple marking styles including linear, angular, radial, inverted, and mirror engraving, allowing diverse marking applications.
Yes, the machine can mark logos, alphanumeric characters, serial numbers, dates, and graphical content with multiple font options.
Country Of Origin: India
• Industrial marking and engraving are rapidly growing industry in the world. Particularly because there is virtually no limit to the number of materials that can be marked or engraved whether you are using metal or non-metal. The operation is simple and lifelong maintenance – free.
