COLOUR COATED STEEL SHEETS

Inclusive of all taxes

COLOUR COATED STEEL SHEETS from AVREX iINTERNATIONAL are premium pre-painted steel solutions designed for demanding roofing, cladding, and general fabrication applications. Manufactured in both PPGL (Pre-Painted Galvalume) and PPGI (Pre-Painted Galvanized Iron) variants, these sheets combine corrosion resistance, mechanical strength, and long-lasting color retention in one performance-driven product. The PPGL version is built on IS 15961 base substrate and IS 15965 colour-coated standards, with grade options from 250 to 550 MPa depending on customer requirement. It offers a total coated thickness range of 0.20 mm to 1.5 mm, width up to 1550 mm, and Al-Zn coating between 150 and 200 g/m². The paint systems available include RMP, SMP, SDP, and PVDF, allowing buyers to select a coating level that matches the required environment, durability, and finish. The top side uses primer plus polyester paint coating with a minimum of 25 microns, while the back side uses primer epoxy with a minimum of 10 microns. For high-performance exposure conditions, salt spray resistance reaches 1000+ hours when SDP or PVDF coatings are used, and SRI values can be 80 or higher depending on the shade. The PPGI version offers thickness from 0.30 mm to 0.80 mm, width range from 1000 mm to 1250 mm, and grade options from 250 to 550 MPa. It is available with ZM coating from ZM 80 to ZM 200 and the same premium paint options of RMP, SMP, SDP, and PVDF. The specification structure is well suited for industrial roofing sheets, pre-engineered buildings, wall cladding panels, architectural applications, canopies, sheds, warehouses, and customized steel fabrication projects. A major advantage of these colour coated steel sheets is the balance between performance and appearance. They deliver strong structural integrity while offering attractive color choices such as Blue, White, Green, Grey, Brown, and Red. This makes them ideal for projects where visual appeal matters as much as durability. In addition, the eco-conscious manufacturing approach supports modern construction and industrial buyers seeking sustainable material choices without compromising strength or service life. With a coil weight range of 3 to 8 tons per coil, these sheets are also suitable for large-scale procurement and continuous production lines. As a B2B-grade material, COLOUR COATED STEEL SHEETS are designed for bulk industrial supply, export-ready usage, and custom specification requirements. Buyers looking for high-durability painted steel sheets, corrosion-resistant roofing coils, or color-coated galvanized steel for factory and infrastructure projects will find this product a reliable and versatile choice.

Key Features

Features Description
Product Type Colour coated steel sheets available in PPGL and PPGI variants
Corrosion Resistance Galvalume and galvanized base with high-performance protective paint systems
Thickness Range PPGL: 0.20 mm to 1.5 mm; PPGI: 0.30 mm to 0.80 mm
Width Range Up to 1550 mm for PPGL; 1000 mm to 1250 mm for PPGI
Coating Options RMP, SMP, SDP, and PVDF
Color Options Blue, White, Green, Grey, Brown, and Red
Durability Performance Salt spray resistance of 1000+ hours with SDP/PVDF coatings
Aesthetic Finish Pre-painted finish designed for architectural and industrial visual appeal
Attributes Description
Product Type COLOUR COATED STEEL SHEETS
Variants PPGL (Pre-Painted Galvalume) and PPGI (Pre-Painted Galvanized Iron)
Base Substrate IS 15961
Colour Coated Standard IS 15965
Grade 250 to 550 MPa (as per customer requirement)
Thickness - PPGL 0.20 mm to 1.5 mm (Total Coated Thickness)
Thickness - PPGI 0.30 mm to 0.80 mm
Width - PPGL Up to 1550 mm
Width - PPGI 1000 mm to 1250 mm
Width Tolerance ±0 mm
Al-Zn Coating 150 to 200 g/m²
ZM Coating ZM 80 to ZM 200
Paint System RMP, SMP, SDP, PVDF
Top Side Coating - PPGL Primer + Polyester Paint Coating, minimum 25 microns
Back Side Coating - PPGL Primer Epoxy, minimum 10 microns
Top Coat - PPGI Primer + up to 20µ
Bottom Coat - PPGI Primer + 5µ
Coil Weight 3 to 8 tons per coil
Salt Spray Resistance ≥ 1000 hours (with SDP / PVDF paints)
SRI Value ≥ 80 (subject to shade specific)
Color Options Blue, White, Green, Grey, Brown, Red

*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.

Be the first to write a review

The PPGL version uses a galvalume base with Al-Zn coating for enhanced corrosion resistance and higher durability, while the PPGI version uses a galvanized iron base with ZM coating options and is typically selected for applications requiring reliable performance at different thickness ranges.

The available paint systems are RMP, SMP, SDP, and PVDF. RMP is suitable for standard use, SMP offers improved durability, SDP is ideal for more demanding outdoor exposure, and PVDF is preferred for high-end weather resistance and long service life.

Yes. The PPGL variant with 150 to 200 g/m² Al-Zn coating and SDP or PVDF paint systems is suitable for harsher environments, delivering salt spray resistance of 1000+ hours.

PPGL sheets are available from 0.20 mm to 1.5 mm thickness and up to 1550 mm width. PPGI sheets are available from 0.30 mm to 0.80 mm thickness and 1000 mm to 1250 mm width.

Yes. These sheets are designed for roofing, cladding, wall panels, sheds, warehouses, and pre-engineered building applications where strength, corrosion resistance, and visual finish are important.

The available color options include Blue, White, Green, Grey, Brown, and Red, making them suitable for architectural and project-specific design requirements.

  • Incorporation Type

  • GST

  • GST Registration Date

  • Number of Employees

  • Import Export Code (IEC)

  • Year of Establishment

  • Nature of Business

  • GlobalLinker Member Since

Country Of Origin: India

COLOUR COATED COILS PPGL (Pre-Painted Galvalume)

Parameter

Specification

Technical Standard

Base Substrate: IS 15961 Colour Coated: IS 15965

Grade

250 to 550 MPa (as per customer requirement)

Thickness

0.20 mm – 1.5 mm (Total Coated Thickness)

Width

Up to 1550 mm

Al-Zn Coating

150 – 200 g/m²

Color Options

Blue, White, Green, Grey, Brown & Red.

Paint System

RMP, SMP, SDP & PVDF

Top Side Coating

Primer + Polyester Paint Coating (Min. 25 microns)

Back Side Coating

Primer Epoxy (Min. 10 microns)

Coil Weight

3 – 8 Tons per Coil

Salt Spray Resistance

≥ 1000 Hours (with SDP / PVDF Paints)

SRI Value

≥ 80 (Subject to Shade Specific)




COLOUR COATED COILS PPGI (Pre-Painted Galvanized Iron)

Parameter

Specification

Thickness (mm)

0.30 – 0.80 mm

Width Range

1000 – 1250 mm

Width Tolerance

±0 mm

Grade

250 to 550 MPa (as per customer requirement)

ZM Coating

ZM 80 – ZM 200

Paint Type

RMP / SMP / SDP / PVDF

Top Coat – DFT (µ)

5µ Primer + Up to 20µ *

Bottom Coat – DFT (µ)

5µ Primer + 5µ *

Durability Redefined

Experience the ultimate blend of strength and sophistication with our COLOUR COATED STEEL SHEETS. Crafted with precision to withstand the test of time, these sheets offer unparalleled durability that ensures your structures remain solid and secure. Say goodbye to frequent replacements and hello to long-lasting quality.


Vibrant Aesthetics

Elevate the visual appeal of your projects with our COLOUR COATED STEEL SHEETS. Available in a wide array of captivating shades, these sheets don't just protect but also enhance the aesthetic charm of your buildings. From modern sleek designs to timeless classics, our sheets offer versatility that complements any architectural style.


Environmental Responsibility

Make a sustainable choice with our COLOUR COATED STEEL SHEETS. Manufactured using eco-friendly processes, these sheets not only prioritize performance but also take a stand for the environment. Reduce your carbon footprint without compromising on quality, as our sheets embody the perfect balance between strength and sustainability.


Features
  • High durability
  • Wide range of colors
  • Environmentally friendly manufacturing processes
