Our High-Density Polyethylene (HDPE) Pipes and Fittings are engineered with premium export quality raw materials to offer unmatched durability, flexibility, and corrosion resistance. Specially designed for industrial and infrastructure applications, these HDPE pipes feature superior mechanical and chemical resistance properties, ensuring reliable, leak-proof performance in harsh environments. Ideal for water supply, irrigation systems, sewage, industrial fluid transport, and gas distribution, these pipes and fittings comply with stringent international standards and offer a service life of up to 100 years. The heat-fused joints guarantee leak-free connections and reduce maintenance costs significantly. Available in a broad range of diameters (16 mm to 1200 mm) and customizable wall thicknesses, our HDPE pipes are lightweight, UV stabilized, and able to accommodate ground movement and cyclic loading, making them well-suited for complex installations including trenchless methods. Manufactured through precise extrusion and injection molding processes with strict quality control, these pipes are supplied globally with competitive pricing and flexible shipping options, cementing their position as preferred choice for demanding industrial and municipal projects.
Key Features
| Features | Description |
|---|---|
| Material | High-Density Polyethylene (HDPE) |
| Corrosion Resistance | Outstanding resistance to acids, alkalis, salts, and organic solvents |
| Mechanical Strength | Minimum Required Strength (MRS) of 10.0 MPa and tensile strength at yield of 23 MPa |
| Service Life | Designed for up to 100 years of maintenance-free operation |
| Joint Technology | Heat-fused, leak-proof joints eliminate leakage risks |
| Flexibility | High flexibility enables complex layouts and tolerates ground movements |
| Temperature Resistance | Melting point approximately 132°C with low thermal expansion coefficient |
| Available Sizes | Outer diameter range from 16 mm to 1200 mm with customizable wall thickness |
| Surface Finish | Smooth internal surface reduces friction loss |
| UV Stabilization | Typically black color for UV resistance with options for color coding |
| Attributes | Description |
|---|---|
| HSN Code | 39172110 (Pipes), 39174000 (Fittings) |
| Density | 930–970 kg/m³ |
| Elongation at Break | >600% |
| Modulus of Elasticity | 200 MPa (50 years) |
| Flexural Modulus | 1000 MPa |
| Thermal Expansion Coefficient | 1.3 x 10⁻⁴ °C⁻¹ |
| Wall Thickness | Varies according to pressure rating PN 2.5 to PN 25 |
| Color Options | Black (UV stabilized), Blue, Other colors available for coding |
| Manufacturing Methods | Extrusion for pipes; Injection molding or fusion welding for fittings |
| Packaging | Coils, straight lengths, reels; fittings in cartons or crates |
| Shipping Terms | FOB, CFR, CIF based on customer preference |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
These HDPE pipes offer superior corrosion and chemical resistance, preventing degradation from acids and alkalis commonly found in industrial fluids. Unlike metal pipes, they also feature high flexibility and fatigue resistance to accommodate ground movement and cyclic loads without cracking.
Yes, with pressure ratings ranging from PN 2.5 to PN 25 and a Hydrostatic Design Basis of 11 MPa, these pipes are engineered to safely handle high pressure typically encountered in gas distribution networks.
Heat-fused joints create a homogenous, leak-proof connection that is stronger than the base pipe material. This eliminates leakage risks, reduces maintenance costs, and ensures long-term integrity of pipelines in potable water supply systems.
Yes, HDPE pipes are available in a wide range of outer diameters from 16 mm up to 1200 mm, with customizable wall thicknesses based on pressure ratings. Color options such as blue and others are offered for specific coding needs.
HDPE pipes should be stored in cool, shaded areas away from direct prolonged sunlight to prevent UV degradation, ensuring preservation of their mechanical and chemical properties until installation.
Brand: kaizen bms
Country Of Origin: India
HSN Code 39172110 (Tubes of polyethylene); 39174000 (Fittings for pipes of plastics)
Category Building Materials / Industrial Plastics
Subcategory Piping Systems / HDPE Pipes & Fittings
• Minimum Required Strength (MRS): 10.0 MPa
• Hydrostatic Design Basis (HDB): 11 MPa
• Tensile Strength at Yield: 23 MPa
• Elongation at Break: >600%
• Modulus of Elasticity: 200 MPa (50 years)
• Flexural Modulus: 1000 MPa
• Thermal Expansion Coefficient: 1.3 x 10⁻⁴ °C⁻¹
• Service Life: Up to 100 years
• Material: High-density polyethylene (HDPE)
• Density: 930–970 kg/m³
• Melting Point: ~132°C
• Resistant to acids, alkalis, salts, and organic solvents
• Non-toxic and suitable for potable water
• Color: Typically black (UV-stabilized), blue, or other colors for coding
• Outer Diameter Range: 16 mm to 1200 mm (customizable)
• Wall Thickness: As per pressure rating (PN 2.5 to PN 25)
• Smooth internal surface (low friction loss)
• Lightweight (density ~0.95 g/cm³)
• High impact and abrasion resistance
• Excellent flexibility (can accommodate ground movement)
• High fatigue resistance (suitable for cyclic loading)
• Puncture and crack resistance
• Raw Material Preparation: Selection and quality check of HDPE resin pellets.
• Extrusion: Resin is melted and extruded through a die to form continuous pipes.
• Sizing & Cooling: Pipes are sized and cooled (water or air) to retain shape.
• Cutting & Inspection: Pipes are cut to length and inspected for quality.
• Fittings Fabrication: Injection molding or fusion welding to create elbows, tees, flanges, etc.
• Quality Control: Pressure testing, dimensional checks, and visual inspection.
• Potable water supply and distribution
• Irrigation and agricultural pipelines
• Sewage and drainage systems
• Industrial fluid and gas transport
• Mining and slurry lines
• Cable ducting and conduit
• Firefighting systems
• Marine and underwater pipelines
• Global Demand: Valued at USD 21.09 billion in 2024, projected to reach USD 30.80 billion by 2033 (CAGR 4.09%). Growth driven by infrastructure, agriculture, and water management projects worldwide.
• Indian Supply: India is a major manufacturer and exporter, with a strong presence in Asia-Pacific (44.1% market share in 2024). Indian HDPE pipes are recognized for quality, competitive pricing, and compliance with international standards.
• Packaging: Supplied in coils (for smaller diameters), straight lengths (sticks), or on reels. Fittings are packed in cartons or crates.
• Shipping Methods: By truck (flatbed, LTL, or enclosed trailer), containerized sea freight, or air freight for urgent orders.
• Dimensions & Weight:
• Bulk Packaging: Palletized and shrink-wrapped for protection and easy handling.
• Storage: Store in cool, shaded areas; avoid direct sunlight for extended periods.
• FOB (Free On Board)
• CFR (Cost and Freight)
• CIF (Cost, Insurance, and Freight)
These terms provide flexibility to clients based on their shipping and insurance preferences.
