The Spring Isolation Systems Series MCI by Dynemech is engineered to provide superior anti-vibration control tailored to the specific needs of various machines in the Indian industrial landscape. With over 10 years of expertise in offering comprehensive vibration control solutions, Dynemech stands as the only provider that supplies all types of vibration solutions under a single umbrella. The MCI-E2 model is particularly adept at accommodating heavy machinery such as presses, hammers, and generator sets, enhancing performance through effective phase differences in operational frequencies. The spring isolator uniquely combines the elements of desired natural frequency adjustments with viscous damping to mitigate excessive movement that often occurs when machines operate near their resonant frequencies. This results in improved reliability, device longevity, and safety in environments with significant vibrations, making it an indispensable choice for industries seeking robust and efficient anti-vibration solutions.
Key Features
| Features | Description |
|---|---|
| Load Capacity | 96 Kg |
| Overall Height (HO) | 80 mm |
| Free Height (HI) | 105 mm |
| Bolt Size | M16x2.0x150 |
| Top Plate Dimensions (AXB) | 221 x 196 mm |
| Bottom Plate Dimensions (CXD) | 271 x 176 mm |
| Center Distance (CC) | 241 mm |
| Natural Frequency Range | 3.5 - 11 Hz |
| Viscous Damping | Integrated for motion control |
| Attributes | Description |
|---|---|
| Model | MCI-E2 |
| Load Capacity | 96 Kg |
| Bolt Size | M16x2.0x150 |
| Free Height (HI) | 105 mm |
| Overall Height (HO) | 80 mm |
| Top Plate Dimensions | 221 x 196 mm |
| Bottom Plate Dimensions | 271 x 176 mm |
| Natural Frequency Range | 3.5 - 11 Hz |
| Viscous Damping | Yes |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
The MCI-E2 spring isolator is designed for heavy machinery, including presses, hammers, and generator sets, providing effective vibration control tailored to their operational frequencies.
Viscous damping is crucial in the MCI-E2 model as it limits excessive movement during operation, particularly when machines are nearing their resonant frequencies, ensuring smoother functioning and reducing risk of damage.
Yes, the MCI-E2 model is rated for a load capacity of 96 Kg and can effectively accommodate fluctuations within this capacity while maintaining optimal performance.
The MCI-E2 isolator has specific dimensions for top and bottom plates (221x196 mm and 271x176 mm respectively) and center distance (241 mm), which should be adhered to for effective installation.
The natural frequency range of the MCI-E2 is specified between 3.5 to 11 Hz, allowing for effective tuning to match the operational frequency of various heavy machinery.
Brand: dynemech
Country Of Origin: India
Dynemech Spring Isolator
Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine.
Model:MCI-E2 Load(Kg):96 HO:80 Free Height HI (mm):105 Bolt Size: M16x2.0x150 Top Plate AXB(mm):221X196 Bottom Plate CXD(mm):271X176 CC(mm):241 Natural Frequency Range(Hz):3.5-11
Freight Will Be Extra
Dynemech Spring Isolator
Dynemech is providing anti vibration solutions to the Indian Industry for the last 10 years. We are the only company to provide almost all types of vibration control solutions under one roof. Our product range consists of stud mounts for very small machines to wedge mounts for precision machine tools, along with air springs for very low natural frequency vibration damping to spring isolators for heavy presses, hammers, gen sets etc. A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine.
Viscous Damping is an important feature of an isolation system. In most cases viscous damping is required to limit excessive movement which could occur as a machine operates at a speed near to, or coinciding with the resonant frequencies of the system. Generally this problem arises during slow run up and run down of rotating machines and during impact at each stroke in presses and hammers.
