Introducing our high-performance Rotameters, designed for precise gas flow regulation and measurement. These versatile instruments offer a unique capability to utilize interchangeable floats tailored to specific flow ranges, making them ideal for various industrial and scientific applications. The rotameter is encased in a robust housing and can reliably measure flow rates for gases under a maximum pressure of 200 psig (13.8 bar) and maximum temperatures of 250 °F (121 °C). This product guarantees accurate and efficient flow management in your gas delivery systems, whether mounted directly or on a tripod assembly. With easy installation and a range of flow rate options, our rotameters are the perfect solution for professionals looking for accuracy and reliability in fluid measurement.
Key Features
| Features | Description |
|---|---|
| Max. Pressure | 200 psig (13.8 bar) |
| Max. Temperature | 250 °F (121 °C) |
| Connections | 1/8 in. female NPT |
| Interchangeable Floats | Four floats for varied flow rates offering customization for specific applications. |
| Flow Rate Ranges | Multiple ranges provided: 0-33, 0-110, 0-246, and 0-454 mL/min. |
| Standard Flow Tables | Included for accurate reference at Standard Temperature and Pressure (STP). |
| Installation Flexibility | Easily mounted or can be used with a tripod assembly. |
| Optional Needle Valve | Available with or without needle valve for additional flow control. |
| Attributes | Description |
|---|---|
| Max. Pressure | 200 psig (13.8 bar) |
| Max. Temperature | 250 °F (121 °C) |
| Connection Size | 1/8 in. female NPT |
| Rotameter Floats | Glass, Sapphire, Stainless Steel, Carboloy |
| Float Flow Rates (0-33 mL/min) | Glass Float: 6 mL/min, Sapphire Float: 8 mL/min, Stainless Steel Float: 17 mL/min, Carboloy Float: 33 mL/min |
| Float Flow Rates (0-110 mL/min) | Glass Float: 19 mL/min, Sapphire Float: 30 mL/min, Stainless Steel Float: 61 mL/min, Carboloy Float: 110 mL/min |
| Float Flow Rates (0-246 mL/min) | Glass Float: 49 mL/min, Sapphire Float: 73 mL/min, Stainless Steel Float: 137 mL/min, Carboloy Float: 246 mL/min |
| Float Flow Rates (0-454 mL/min) | Glass Float: 92 mL/min, Sapphire Float: 140 mL/min, Stainless Steel Float: 264 mL/min, Carboloy Float: 454 mL/min |
| Installation Options | Mountable or tripod assembly (tripod sold separately) |
| Needle Valve | Available option for precise flow control. |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
The rotameter features interchangeable floater options including Glass, Sapphire, Stainless Steel, and Carboloy, each with distinct flow rate capabilities.
Yes, the rotameter is available with or without an optional needle valve, giving users flexibility based on their flow control needs.
The rotameter can measure flow rates up to 454 mL/min, depending on the specific float used.
Yes, the rotameter is designed for easy installation with a 1/8 in. female NPT connection and can be mounted directly or on a tripod.
Yes, standard flow tables at STP (Standard Temperature and Pressure) are included for accurate measurement references.
Country Of Origin: India
Specifications:
Max. Pressure: 200 psig (13.8 bar)
Max. Temp.: 250 °F (121 °C)
Connections: 1/8 in. female NPT (use connector to male NPT fittings to connect into gas delivery system)
Float Upper Flow Rates
0-33 mL/min. Rotameter
Glass Float: 6 mL/min.
Sapphire Float: 8 mL/min.
Stainless Steel Float: 17 mL/min.
Carboloy Float: 33 mL/min.
0-110 mL/min. Rotameter
Glass Float: 19 mL/min.
Sapphire Float: 30 mL/min.
Stainless Steel Float: 61 mL/min.
Carboloy Float: 110 mL/min.
0-246 mL/min. Rotameter
Glass Float: 49 mL/min.
Sapphire Float: 73 mL/min.
Stainless Steel Float: 137 mL/min.
Carboloy Float: 246 mL/min.
0-454 mL/min. Rotameter
Glass Float: 92 mL/min.
Sapphire Float: 140 mL/min.
Stainless Steel Float: 264 mL/min.
Carboloy Float: 454 mL/min.
Description
General description
This rotameter is designed for the accurate regulation of gas flow, providing measurement at the same time. This versatile unit includes four interchangeable floats, each with a different working range. Simply install the float required for the application. Standard flow tables in mL/min at STP are included.
The rotameter is easy to mount. Alternatively, it can be installed on a tripod assembly (order tripod assembly separately). Available with or without needle valve.
