MULTICORE FLEXIBLE CABLES are designed for power distribution, control wiring, and equipment connections in industrial, commercial, and infrastructure projects. Built for B2B procurement, these cables are suitable for wholesale supply, bulk order requirements, OEM projects, and factory direct sourcing where reliable electrical performance and flexible installation are essential. The cable construction uses bare copper or tinned copper conductors, giving buyers a choice between standard conductivity and improved corrosion resistance for harsher environments. Insulation options include PVC, HRPVC, FRLS, FR, and LSZH, allowing selection based on temperature resistance, flame-retardant needs, smoke emission levels, and safety requirements. For flexible cable variants, the sheath is available in PVC, FRLS, LSZH, or FR for added mechanical and environmental protection. These cables are rated up to 1100 V and cover a wide range of industrial grade applications. They are used in control panels, machinery, plant wiring, electrical assemblies, networking-related infrastructure, and other systems requiring dependable multicore cable routing. The multicore format supports compact wiring layouts and reduces installation complexity in projects where multiple conductors must be managed together. Applicable standards include BS 6004, BS 6500, IS 694, IS 8130, IS 10418, BS 7655, IEC 60228, BS 6360, BS 7211, and BS EN 50525-3-41, making these cables export-ready for regulated markets and compliance-driven procurement. This standards coverage helps buyers source cables for projects that require recognized conductor, insulation, and low-smoke halogen-free performance specifications. The product range includes single core flexibles from 0.5 sq.mm. up to 1000 sq.mm., and multicore flexible cables from 0.5 sq.mm. up to 120 sq.mm. in 2C to 4C configurations, with smaller sizes up to 2.5 sq.mm. available up to 24C. Packing options include coils, wooden drums, steel drums, and ABS reels, supporting project logistics, warehouse handling, and export shipment needs. Customized cable design is available as per project or customer requirement, with cable accessories offered if required. MOQ is 1 metre, making it suitable for both sample procurement and larger bulk supply programs.
Key Features
| Features | Description |
|---|---|
| Conductor Material | Bare Copper / Tinned Copper |
| Insulation Options | PVC, HRPVC, FRLS, FR, LSZH |
| Sheath Options | PVC, FRLS, LSZH, FR |
| Voltage Grade | Up to 1100 V |
| Applicable Standards | BS 6004, BS 6500, IS 694, IS 8130, IS 10418, BS 7655, IEC 60228, BS 6360, BS 7211, BS EN 50525-3-41 |
| Multicore Range | 0.5 sq.mm. to 120 sq.mm. |
| Core Configuration | 2C to 4C; up to 24C in smaller sizes |
| Packing | Coils, Wooden/Steel Drums, ABS Reels |
| Customization | Customized cable design available |
| Attributes | Description |
|---|---|
| Product Name | MULTICORE FLEXIBLE CABLES |
| Store Name | HVH GLOBAL |
| Minimum Order Quantity | 1 Metre |
| Conductor | Bare Copper / Tinned Copper |
| Insulation | PVC / HRPVC / FRLS / FR / LSZH |
| Sheath (for flexible cables) | PVC / FRLS / LSZH / FR |
| Voltage Grade | Up to 1100 V |
| Applicable Standards | BS 6004, BS 6500, IS 694, IS 8130, IS 10418, BS 7655, IEC 60228, BS 6360, BS 7211, BS EN 50525-3-41 |
| Single Core Flexible Range | 0.5 sq.mm. up to 1000 sq.mm. |
| Multicore Flexible Range | 0.5 sq.mm. up to 120 sq.mm. |
| Core Count for Multicore Range | 2C to 4C |
| Small Size Core Count | Up to 24C |
| Smaller Size Limit | Up to 2.5 sq.mm. |
| Packing Options | Coils, Wooden/Steel Drums, ABS Reels |
| Customization | Customized cable design as per project/customer requirement available |
| Accessories | Cable accessories can be offered if required |
| Product Type | Multicore flexible cable |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
The cables are available with bare copper or tinned copper conductors, allowing buyers to choose between standard conductivity and improved corrosion resistance.
Insulation options include PVC, HRPVC, FRLS, FR, and LSZH. For flexible cable sheath options, PVC, FRLS, LSZH, and FR are available.
The voltage grade is up to 1100 V.
Applicable standards include BS 6004, BS 6500, IS 694, IS 8130, IS 10418, BS 7655, IEC 60228, BS 6360, BS 7211, and BS EN 50525-3-41.
The multicore flexible cable range is 0.5 sq.mm. up to 120 sq.mm., with 2C to 4C configurations, and smaller sizes up to 2.5 sq.mm. available up to 24C.
Yes, customized cable design is available as per project or customer requirement.
Packing options include coils, wooden drums, steel drums, and ABS reels, depending on size and requirement.
The minimum order quantity is 1 metre.
Country Of Origin: India
Bare Copper/Tinned Copper: The metallic core of the cable that carries electricity.
Bare copper is untreated copper.
Tinned copper has a thin layer of tin to resist corrosion.
PVC/HRPVC/FRLS/FR/LSZH: The protective layer around the conductor.
PVC: Polyvinyl Chloride (standard insulation).
HRPVC: Heat Resistant PVC.
FRLS: Flame Retardant Low Smoke.
FR: Flame Retardant.
LSZH: Low Smoke Zero Halogen (safer in fire, less toxic fumes).
Outer covering for extra protection. Options: PVC, FRLS, LSZH, FR — same meanings as above.
Up to 1100 V: The maximum voltage these cables can safely carry.
International and national standards that ensure quality and safety, such as BS (British Standards), IS (Indian Standards), IEC (International Electrotechnical Commission).
Supplied in coils, wooden/steel drums, or ABS reels depending on size and requirement.
Single Core Flexible Cables: From 0.5 sq.mm to 1000 sq.mm (cross-sectional area of conductor).
Multicore Flexible Cables: From 0.5 sq.mm to 120 sq.mm, available in 2-core to 4-core.
Smaller sizes up to 2.5 sq.mm can have up to 24 cores.
BS 6004: British Standard for PVC-insulated cables for domestic and light industrial use.
BS 6500: Flexible cords and cables for appliances and equipment.
IS 694: Indian Standard for PVC-insulated cables up to 1100 V.
IS 8130: Specifies conductor requirements for electric cables.
IS 10418: Covers cable sheathing and protective coverings.
BS 7655: Insulation and sheath materials for cables.
IEC 60228: International standard defining conductor classes (solid, stranded, flexible).
BS 6360: Conductors for insulated cables.
BS 7211: Low smoke halogen-free cables.
BS EN 50525-3-41: European standard for flexible cables with special fire performance.
