The DSSE-N ICU Ventilator is a highly advanced medical device designed to deliver precise invasive and non-invasive respiratory support for adult and pediatric patients in critical care environments. This ventilator supports a comprehensive range of ventilation modes including pressure control, volume control, and advanced modes like APRV and High Flow Nasal Cannula, enabling healthcare providers to tailor respiratory therapy to individual patient needs. It features a robust 8-hour internal lithium battery backup ensuring uninterrupted operation during power outages or patient transportation. The DSSE-N supports high flow oxygen therapy with continuous oxygen flow rates between 10 to 75 L/min and FiO2 levels adjustable from 21% to 100%, controlled via closed loop electronic manipulation, guaranteeing optimal oxygen delivery. It includes advanced tools for recruitment maneuvers such as manual breath, O2 boost, inspiratory and expiratory holds, along with 100% leak detection and compensation in non-invasive ventilation modes, making it highly reliable in various clinical scenarios. Equipped with a clear 10-inch TFT screen, this ventilator offers intuitive monitoring and control, while its compact design (396 x 340 x 255 mm) and manageable patient unit weight (10.3 kg) combined with a trolley (25 kg) enhance mobility within ICU settings. Compatible with standard accessories, the DSSE-N ICU ventilator meets rigorous technical standards, delivering flexibility, safety, and efficient respiratory support for critical care facilities and specialized healthcare centers.
Key Features
| Features | Description |
|---|---|
| Ventilation Modes | PC-CMV, PC-AC, PC-SIMV, VC-CMV, VC-AC, VC-SIMV, PRVC-CMV, PRVC-AC, PRVC-SIMV, PS/CPAP (PSV), APRV, High Flow Nasal Cannula (HFNC) |
| Patient Inclusion | Suitable for Adult and Paediatric patients |
| Battery Backup | Internal Lithium battery providing up to 8 hours of backup |
| Oxygen Therapy | High flow oxygen therapy with continuous flow 10-75 L/min, FiO2 21-100% with closed loop electronic control |
| Leak Detection and Compensation | 100% leakage compensation in non-invasive ventilation modes |
| Recruitment Tools | Manual Breath, O2 Boost, Inspiratory Hold, Expiratory Hold for patient lung recruitment |
| Respiratory Rate Range | 1 to 80 breaths per minute |
| Inspiratory Pressure | Peak Inspiratory Pressure up to 80 cm H2O |
| PEEP and Pressure Support | PEEP range 0-50 cm H2O, Pressure Support range 0-60 cm H2O |
| Display | 10-inch TFT touch screen for real-time monitoring and control |
| Attributes | Description |
|---|---|
| Dimensions (Patient Circuit) | 396 x 340 x 255 mm |
| Weight (Patient Unit) | Approximately 10.3 kg |
| Weight (With Trolley) | Approximately 25 kg |
| Battery Type | Internal Lithium Ion |
| Mains Input Voltage | 201-240 V AC, 50-60 Hz |
| Input Current | Not specified |
| Tidal Volume Range | 50 - 2000 mL |
| Inspiratory Time Range | 0.2 - 10 seconds |
| I:E Ratio Range | 1:10 to 10:1 |
| Trigger Flow Sensitivity | 1 - 20 L/min |
| Oxygen Input Pressure | 46-60 PSIG |
| Screen Type | 10 inch TFT Display |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
The DSSE-N ventilator utilizes a closed loop electronic manipulation system to precisely control oxygen concentration (FiO2) from 21% to 100%, ensuring accurate delivery tailored to patient requirements.
The DSSE-N ventilator offers versatile ventilation modes including PC-CMV, VC-CMV, and HFNC, with adjustable tidal volumes ranging from 50 to 2000 mL, making it suitable for both adult and pediatric respiratory care.
It integrates a robust internal lithium battery providing up to 8 hours of backup, allowing continuous ventilation support during power outages or while the patient is being transported.
The ventilator features a 100% leak detection and compensation system specifically designed for non-invasive ventilation modes, ensuring consistent pressure delivery even in the presence of leaks.
Therapies like manual breath, O2 boost, inspiratory hold, and expiratory hold are incorporated to facilitate lung recruitment and improve oxygenation during critical care.
Brand: noccarc
Country Of Origin: India
DSSE-N
FEATURES:
• High Flow Oxygen Therapy
• Advanced Therapy
• 8 Hours Battery Backup
• Non-invasive Therapy
• Compatible with Standard Accessories
TECHNICAL SPECIFICATIONS:
• Patient Inclusions: Adult & Paediatric
• Therapy: Invasive Ventilation, Non-invasive Ventilation, O2 Therapy
• Modes: PC-CMV, PC-AC, PC-SIMV, VC-CMV, VC-AC, VC-SIMV, PRVC-CMV, PRVC-AC, PRVC-SIMV, PS/CPAP (PSV), APRV, High Flow Nasal Cannula (HFNC mode)
• Respiratory rate (RR): 1-80 BPM
• Peak Inspiratory Pressure: 80 cm of H2O
• PEEP: 0 -50 cm of H2O
• Pressure Support: 0 -60 cm of H2O
• Inspiratory Time (Ti): 0.2 -10 s
• I:E Ratio: 1:10 to 10:1
• Tidal Volume (VT): 50 -2000 mL
• Trigger Flow Sensitivity: 1 -20 L/min
• O2 Concentration (FiO2): 21 -100 %
• FiO2 Control: Closed Loop Electronic Manipulation
• Recruitment Tools: Manual Breath, O2 Boost, Inspiratory hold, Expiratory hold
• Leak Detection and Compensation: 100% leakage compensation in NIV modes
• O2 Therapy: Continuous flow 10 -75 L/min, Concentration 21 -100 %
• Oxygen Input: 46-60 PSIG
• Screen10TFT
•Dimensions Patient Circuit: 396 X 340 X 255 mm
• Weight: ~ 10.3 Kg Patient Unit, ~ 25 Kg with Trolley
• Battery: Lithium, Internal
• Battery Back-up Time: Upto 8 hours
• Mains Input: 201 -240V AC, 50 -60 Hz
• Input Current: <2.00 A
• Power Consumption: <150 W
• Pressure Measurements: Peak Inspiratory Pressure (PIP), Positive End Expiratory Pressure (PEEP), Plateau Pressure (Pplat ), Mean Pressure (Pmean ), Range: 0 to 100 cm H2O
• Flow Measurements: Expiratory Minute Volume (MVe ), Inspiratory Minute Volume (MVi ), Spontaneous Expired Minute Volume (Spont. MVe ), Range 0 to 160 L/min
• Volume Measurements: Inspiratory Tidal Volume (VTi ), Expiratory Tidal Volume (VTe ), Total Leak Volume
• Other Measurements: Oxygen Concentration (FiO2 ), Respiratory Rate (RR)
I:E Ratio, Rapid Shallow Breathing Index (RSBI), Dynamic Lung Compliance (Cdyn), Inspiratory Time (Ti), Expiratory Time (Te)
• Trends: Storage of trends for last 96 hours of all parameters
• Dimensions: 396mm x 340mm x 255mm
• Weight: Patient unit= 10.1 kg, With Trolley= 24 kg
