HORIZONTAL LAMINAR FLOW CABINET "MAC" MSW-161

Inclusive of all taxes

The HORIZONTAL LAMINAR FLOW CABINET "MAC" MSW-161 is a premium clean air workstation engineered for contamination-sensitive tasks. Constructed from high-quality CRC sheet with durable powder coating, this cabinet ensures long-lasting performance in laboratory and industrial environments. The stainless steel (SS-304 grade) working table offers corrosion resistance and easy cleaning, ideal for sterile procedures. Its thick transparent toughened glass front door provides optimal visibility while maintaining safety. Equipped with a heavy-duty, low-noise motor, the cabinet maintains a consistent laminar airflow to prevent particle contamination. The internal workspace is well illuminated by a 40W fluorescent lamp, facilitating precise work. This model integrates a factory-fitted HEPA filter conforming to EU-14 standards, providing filtration efficiency above 99.999% for particles as small as 0.3 microns. Additionally, a washable, cleanable pre-filter enhances lifespan and performance of the main filter. The built-in UV germicidal lamp sterilizes the work area for aseptic operations. Utility cocks for gas, air, or vacuum lines are incorporated for versatile laboratory applications. Mounted on a robust tubular stand with levelers, the MSW-161 model ensures ergonomic comfort and stability. Its compact internal workzone dimension of 600x610x675 mm makes it suitable for various workspace sizes. Overall, this laminate flow cabinet is ideal for microbiology, pharmaceutical, electronics assembly, and other contamination-sensitive processes, combining superior filtration, durability, and ease of use for professional B2B applications.

Key Features

Features Description
Construction Material CRC Sheet with Powder Coating
Working Table Stainless Steel Sheet (SS-304 Grade)
Front Door Material Thick Transparent Toughened Glass
Motor Heavy Duty, Low Noise Level
Lighting 40W Fluorescent Lamp for Work Area Illumination
UV Sterilization Built-in UV Germicidal Tube
Main HEPA Filter EU-14 Grade, >99.999% Efficiency at 0.3 μm, Micro Fine Glass Fibre Media
Pre-filter Non-Woven Synthetic with HDPE & Al Expanded Mesh, Washable and Cleanable
Front Door Type Plexi Glass
Utility Cock Gas, Air, or Vacuum Line
Mounting Heavy Tubular Stand with Levelers
Internal Workzone Dimension (LxWxH) 600x610x675 mm
Number of HEPA Filters 1
Attributes Description
Model Number MSW-161 (LH-22)
Cabinet Material CRC Sheet with Powder Coating
Work Table Material SS-304 Grade Stainless Steel
Front Door Material Toughened Plexi Glass
Filtration Efficiency >99.999% at 0.3 μm
HEPA Filter Specification EU-14 Grade, Imported Micro Fine Glass Fibre Media
Prefilter Specification Non-Woven Synthetic, HDPE Mesh, Al Expanded Mesh, Washable
Illumination 40W Fluorescent Lamp
Sterilization UV Germicidal Tube
Motor Sound Level Minimum Noise Level
Utility Connections Gas, Air, Vacuum Cock
Stand Type Heavy Tubular with Levelers
Workzone Dimensions 600x610x675 mm
Number of HEPA Filters 1

*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.

Be the first to write a review

The HEPA filter in the MSW-161 meets EU-14 Grade standards with an efficiency rating better than 99.999% for particles of 0.3 microns.

Yes, the pre-filter is washable and cleanable using compressed air, which helps extend the life of the main HEPA filter.

The working table is constructed from stainless steel sheet, SS-304 grade, to ensure durability and resistance to corrosion.

Yes, the MSW-161 features a built-in UV germicidal tube to sterilize the work area and maintain aseptic conditions.

The cabinet includes utility cocks for gas, air, or vacuum lines to suit various laboratory needs.

  • Incorporation Type

  • GST

  • GST Registration Date

  • Number of Employees

  • Import Export Code (IEC)

  • Year of Establishment

  • Nature of Business

  • GlobalLinker Member Since

Country Of Origin: India

Cabinet is fabricated of CRC Sheet duly powder coated.

Working table is made of Stainless Steel Sheet (SS-304 grade).

Front doors are made out of thick transparent toughened glass.

Heavy Duty Motor operates with minimum noise level.


Working area is illuminated by fluorescent lighting fitted to the unit.

Supplied complete with S.S. Satin finish Table Top, Transparent front door, Built in U.V. Germicidal light and Cock for gas, air or vacuum line, HEPA filters and pre-filter.

Mounted on heavy tubular stand with levelers.

Main filter : HEPA Filter made from water resistant, fire retardant, imported micro fine glass fibre media; conforms to EU - 14 Grade, with an efficiency rating better than 99.999% for 0.3 μ. These filters are designed to accommodate higher airflow volume.

Prefilter : Prefilter are made from Non-Woven Synthetic with HDPE mesh and Al expanded mesh on air leaving side; conforms to EU-4/G-4 Grade, with efficiency of 90% down to 10 micron. These filters can be cleaned by compressed air & also washable.

Illumination : Fluorescent Lamp 40W

Sterilizing : UV Germicidal Tube.

Front door : Made of plexi Glass

Utility : Gas/Air cock

MODEL : #LH-22

Internal Workzone Dimension (LxWxH) (mm) : 600x610x675

NO. of HEPA Filter : 1
