The CNC Back Plate with Collet System is a precision-engineered component designed for CNC machines to ensure high accuracy and secure holding of workpieces during machining processes. Manufactured with durable materials to withstand rigorous industrial usage, this back plate integrates a collet system that offers enhanced concentricity and grip for various sizes of tools and workpieces. Its modular design allows for quick installation and interchangeability, making it an ideal solution for CNC machining centers requiring reliable clamping and reduced setup times. This product minimizes run-out and vibration during high-speed operations, contributing to improved surface finish and machining accuracy. Compatible with a wide range of CNC lathe and milling machines, this back plate with collet system supports diverse industrial applications such as automotive, aerospace, and tool manufacturing sectors.
Key Features
| Features | Description |
|---|---|
| Compatibility | Fits various CNC lathe and milling machines |
| Material | High-grade alloy steel for durability |
| Collet System | Precision collet for secure and concentric clamping |
| Design | Modular design for easy installation and interchangeability |
| Performance | Minimizes vibration and run-out during machining |
| Application | Suitable for automotive, aerospace, and tool manufacturing |
| Size Range | Supports multiple collet sizes for versatile use |
| Mounting | Back plate mounting with precise alignment features |
| Attributes | Description |
|---|---|
| Outer Diameter | Varies (commonly 150mm to 300mm) |
| Thickness | Typically 20mm to 50mm |
| Collet Diameter Range | Supports from 6mm to 25mm collets |
| Material Grade | Alloy Steel Grade 42CrMo4 |
| Surface Finish | Precision machined to Ra 0.8 or better |
| Max RPM | Up to 6000 RPM depending on machine compatibility |
| Weight | Approximately 2 kg to 6 kg depending on size |
| Mounting Bolt Pattern | Standardized according to machine model |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
The back plate supports standard ER and precision collet systems ranging from 6mm to 25mm in diameter, adaptable to various toolholding needs.
Yes, it is precision balanced and designed to operate safely up to 6000 RPM, minimizing vibration and ensuring stable machining.
Custom versions can be manufactured to match specific mounting bolt patterns and dimensions for a wide range of CNC machine models.
Constructed from high-grade alloy steel, specifically Grade 42CrMo4, ensuring wear resistance and long service life under heavy industrial use.
The integrated collet system provides uniform clamping pressure with high concentricity, which reduces run-out and improves machining accuracy.
