CRAFTECH

Features:

Optically Enhanced Lens

▪ Press Fit Lens Design

▪ Compact Size

▪ Multiple Voltage Range

▪ Low Current Consumption

▪ Touch -Safe Screw Terminal connection

▪ Available in Colors : Red, Yellow, Blue, Green, Amber, & White

Waterproof and Coolant proof Lights for CNC/VMC machineries

The LED light is available in standard version and can be customized to size and wattage as per customer for specific application requirement.

Flexible Gooseneck LED Spot light 4.5W, 24 VDC. Available in 3 sizes 12, 18 & 24 inches

Input Voltage: 24 VDC, in build driver

                       110-230 VAC with external adapter

Power:  4.5 Watt, 12W

LED Driver: Constant current Driver Inbuilt

LED Lens Angle: 40 Deg,

Light diffuser: Clear

LED Type: High Power , 6500K & 3000K

Operating temperature: -10 to +65 Degrees Celcius

Lumens: 1300 lx @ 1 Mtr (+/- 5%)

Degree of Protection: IP 65 Lamp Front & Rear

FALL Series Folding Arm LED Spot Lights suitable for work tables, Inspection Tables, Lathe Machines, Drilling Machines, Special purpose Machines and many more

Features:

1. Flexible movement in all direction

2. Sturdy Design

3. Longer life

Features:

 Bright LED Fault Indication

 Flush mountable on Panel 96x96 mm Panel cutout

 Compact Size

 Wide Operating Voltage Band

 Low Current Consumption

 High Audible sound output

 Available in Multiple Voltage range

LED type SMD2835, LM80 approved

Colour Temp (CCT) 6500 K

Luminous Efficiency 100lm/watt

Beam Angle 120 Deg

CRI (min) 80

Storage Temperature -200C to + 750C

Operating Temperature -100C to + 650C

Protection class IP 20

Service Life 50,000 Hrs. @ 250C

Accessories 2 no’s Clamps for Clamp mounting, Wire for Input Supply or Connector for Input Supply

The RTLL Linear Light are designed to meet the demanding nature of industrial lighting, build on heavy

duty industrial grade Aluminium body. The light is suitable for various applications such as Warehouses,

corridors, Industrial Sheds, Passages, stores areas, Inspection tables, work benches, Machine lighting and

more.

Features

 Diffused Cool White Light for Strain less Working

 Powder coated aluminum body

 Sleek & Compact Design

 Longer Life of 50000 Hours

 Quick and Easy to Install

Features:

1. Aluminium Body 6063 grade

2. Frosted glass 4 mm thickness

3. LED Light available with Lens and without lens

4. Compact and easy to install.

5. Light position can be adjusted with tilting bracket..

Application:

Heavy Duty CNC/VMC Machines, Boiler Machines, Special Purpose Machines and many more
