The Automatic Volumetric Cup Filler Sachet Packing Machine is expertly engineered for the high-speed, precise packaging of free-flowing granules and powders within a dosage range of 1 gm to 10 gm. Utilizing an adjustable volumetric cup filling mechanism, this machine ensures consistent micro-dosing accuracy with a tolerance of ±1% to 2%, making it particularly suitable for industries requiring meticulous portion control. Constructed with GMP-compliant stainless steel (SS 304/SS 316) contact parts, it caters to both pharmaceutical and non-pharmaceutical sectors, including applications like Ayurvedic powders, ORS, spices, tea/coffee premixes, and agrochemicals. The machine features versatile pouch sealing options (center seal, 3-side, or 4-side seals) along with a customizable pouch size range (width: 25-100mm; length: 50-250mm). Its fully automatic operation with PLC control, HMI touchscreen, and optional servo-driven dosing increases productivity up to 40-60 sachets per minute. Optional enhancements include nitrogen flushing for product preservation, online batch coding, and efficient product handling accessories, thereby delivering a comprehensive sachet packaging solution optimized for stringent quality and operational standards.
Key Features
| Features | Description |
|---|---|
| Filling Range | 1 gm to 10 gm (Adjustable with change parts) |
| Filling Type | Volumetric Cup Filler (Base) |
| Product Suitability | Free-flowing granules and powders (Pharma & Non-Pharma) |
| Automation Grade | Fully Automatic |
| Contact Parts Material | Stainless Steel SS 304/SS 316 (As per requirement) |
| Sealing Options | Center Seal / 3-Side Seal / 4-Side Seal (Model Dependent) |
| Typical Speed | 40-60 sachets per minute (Dependent on product and film) |
| Control System | PLC Control with HMI Touch Screen |
| Dosing Accuracy | ±1% to 2% |
| Pouch Size Range | Width: 25-100 mm; Length: 50-250 mm (Adjustable) |
| Optional Features | Servo Motors, Nitrogen Gas Flushing, Online Batch Coding, Auto-Feeding System |
| Attributes | Description |
|---|---|
| Model | [Specify machine model name/number] |
| Filling System | Adjustable Volumetric Cup Dosing |
| Pouch Types Supported | Pillow Pouch (Center Seal), 3-Side Seal, 4-Side Seal |
| Power Supply | 220V AC / 440V AC, Single/Three Phase |
| Power Consumption | 1.5 KW to 3 KW (Approx.) |
| Air Consumption | 6 CFM @ 6 Bar (For Pneumatic Models) |
| Machine Weight | 200 - 400 Kg (Approximate) |
| Machine Dimensions | [Specify L x W x H in mm] |
| Material Compliance | GMP-certified Stainless Steel Contact Parts |
| Speed Range | Up to 60 sachets per minute depending on product characteristics |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
Yes, the machine's contact parts are made from GMP-compliant stainless steel SS 304 or SS 316, which can be custom selected to meet pharmaceutical and food-grade hygiene standards, minimizing cross-contamination risk.
The adjustable volumetric cup dosing system allows customization of cup sizes and dosing parameters to compensate for different flowability, ensuring filling accuracy within ±1% to 2%.
Yes, depending on the model, it supports center seal, 3-side seal, and 4-side seal sachets, providing flexibility for various packaging designs.
Pouch widths between 25 mm and 100 mm and lengths between 50 mm and 250 mm can be accommodated, with mechanical or electronic adjustments available for length.
Yes, nitrogen gas flushing units are optional add-ons to help preserve sensitive products by reducing oxidation during packaging.
The machine can produce approximately 40-60 sachets per minute; however, the actual speed depends on product flow, filling volume, and type of packaging film used.
Country Of Origin: India
Sachet Packing Volume Base Cup Filler Machine (1-10 gm)
Our Automatic Volumetric Cup Filler Sachet Packing Machine is a highly efficient and reliable solution designed for the fast and accurate packaging of free-flowing granules and powders into small, single-serving sachets or pouches. Utilizing the volumetric cup filling principle, it guarantees uniform dosing accuracy for weights ranging from 1 gm to 10 gm, making it an ideal choice for industries requiring precision micro-dosing
Attribute,Detail
Product Name,Automatic Volumetric Cup Filler Sachet Packing Machine
Filling Range,1 gm to 10 gm (Adjustable with change parts)
Filling Type,Volumetric Cup Filler (Base)
Product Suitability,Free-Flowing Granules & Powders (Pharma & Non-Pharma)
Automation Grade,Fully Automatic
Contact Parts Material,Stainless Steel (SS 304/SS 316 as per requirement)
Sealing Type,Center Seal / 3-Side Seal / 4-Side Seal (Model Dependent)
Typical Speed,"Up to 40-60 sachets per minute (Varies by product, fill volume, and film)"
Parameter,Value / Range
Model,[Specify your machine's model name/number]
Filling System,Adjustable Volumetric Cup Dosing
Filling Accuracy,±1% to 2% (Dependent on product flow characteristics)
Pouch Type,"Pillow Pouch (Centre Seal), 3-Side Seal, or 4-Side Seal"
Pouch Width,Min. 25 mm - Max. 100 mm (Customizable)
Pouch Length,Min. 50 mm - Max. 250 mm (Mechanically/Electronically Adjustable)
Power Supply,"220V AC / 440V AC, Single/Three Phase (As per Model)"
Power Consumption,1.5 KW to 3 KW (Approx.)
Air Consumption,"Required for Pneumatic Models only (e.g., 6 CFM @ 6 Bar)"
Machine Weight,Approx. 200 - 400 Kg
Machine Dimensions,[Specify L x W x H in mm]
Category,Standard Features,Optional Features
Control,"PLC Control, HMI Touch Screen, PID Temperature Controllers",Servo Motor for Enhanced Dosing Precision
Product Handling,"Inter-changeable Cup Sets, Motorised Film Unwinding",Nitrogen Gas Flushing Unit for Product Preservation
Printing,"Batch Cutting, Pouch Counter",Online Batch Coding Device (Inkjet or Hot Foil)
Output,Safety Doors and Emergency Stop,"Pouch Take-off Conveyor, Auto-Feeding System"
Of course, here is a detailed product description and related information for a Sachet Packing Volume Base Cup Filler Machine, suitable for granules and powders from 1 gm to 10 gm, for both pharma and non-pharma applications.
***
## 📦 Sachet Packing Volume Base Cup Filler Machine (1-10 gm)
Our **Automatic Volumetric Cup Filler Sachet Packing Machine** is a highly efficient and reliable solution designed for the fast and accurate packaging of **free-flowing granules and powders** into small, single-serving sachets or pouches. Utilizing the **volumetric cup filling** principle, it guarantees uniform dosing accuracy for weights ranging from **1 gm to 10 gm**, making it an ideal choice for industries requiring precision micro-dosing.
### 🎯 Key Features & Benefits
* **Precise Dosing:** Employs an adjustable **Volumetric Cup Filling** system for consistent and accurate dosing of free-flowing products.
* **Versatile Application:** Perfectly suited for a wide range of products including **Pharmaceutical Granules, ORS Powder, Spices (Masala), Tea/Coffee Premixes, Sugar, Salt, Health Supplements, Agrochemicals,** and fine **Non-Pharma Powders**.
* **High-Quality Construction:** Built with **SS 304 (Stainless Steel)** contact parts, ensuring **GMP (Good Manufacturing Practice)** compliance, especially for sensitive **Pharma and Food-grade** materials.
* **High Speed & Efficiency:** Fully automatic operation handles the entire process—film unwinding, filling, sealing, and cutting—to maximize throughput.
* **User-Friendly Control:** Features an intuitive **PLC Control System** with an **HMI (Human Machine Interface)** touch screen for easy parameter setting, monitoring, and troubleshooting.
***
## 📝 Product Summary (For Business Portal Overview)
| Attribute | Detail |
| :--- | :--- |
| **Product Name** | Automatic Volumetric Cup Filler Sachet Packing Machine |
| **Filling Range** | 1 gm to 10 gm (Adjustable with change parts) |
| **Filling Type** | Volumetric Cup Filler (Base) |
| **Product Suitability** | Free-Flowing Granules & Powders (Pharma & Non-Pharma) |
| **Automation Grade**| Fully Automatic |
| **Contact Parts Material** | Stainless Steel (SS 304/SS 316 as per requirement) |
| **Sealing Type** | Center Seal / 3-Side Seal / 4-Side Seal (Model Dependent) |
| **Typical Speed** | Up to 40-60 sachets per minute (Varies by product, fill volume, and film) |
***
## ⚙️ Additional Information (Detailed Specifications)
### Technical Specifications
| Parameter | Value / Range |
| :--- | :--- |
| **Model** | [Specify your machine's model name/number] |
| **Filling System** | Adjustable Volumetric Cup Dosing |
| **Filling Accuracy**| $\pm 1\%$ to $2\%$ (Dependent on product flow characteristics) |
| **Pouch Type** | Pillow Pouch (Centre Seal), 3-Side Seal, or 4-Side Seal |
| **Pouch Width** | Min. 25 mm - Max. 100 mm (Customizable) |
| **Pouch Length** | Min. 50 mm - Max. 250 mm (Mechanically/Electronically Adjustable) |
| **Power Supply** | 220V AC / 440V AC, Single/Three Phase (As per Model) |
| **Power Consumption**| 1.5 KW to 3 KW (Approx.) |
| **Air Consumption**| Required for Pneumatic Models only (e.g., 6 CFM @ 6 Bar) |
| **Machine Weight** | Approx. 200 - 400 Kg |
| **Machine Dimensions**| [Specify L x W x H in mm] |
### Standard and Optional Features
| Category | Standard Features | Optional Features |
| :--- | :--- | :--- |
| **Control** | PLC Control, HMI Touch Screen, PID Temperature Controllers | Servo Motor for Enhanced Dosing Precision |
| **Product Handling** | Inter-changeable Cup Sets, Motorised Film Unwinding | Nitrogen Gas Flushing Unit for Product Preservation |
| **Printing** | Batch Cutting, Pouch Counter | Online Batch Coding Device (Inkjet or Hot Foil) |
| **Output** | Safety Doors and Emergency Stop | Pouch Take-off Conveyor, Auto-Feeding System |
### Ideal for Packaging
* **Pharmaceutical:** Ayurvedic Churna, ORS Powder, Granules, Fine Powders.
* **Food & Beverages:** Ground Coffee, Tea, Sugar, Salt, Spices (Turmeric, Chili, Coriander powder), Instant Drink Mixes, Seasonings.
* **Chemical/Others:** Detergent Powder, Agrochemicals, Talcum Powder, Free-Flowing Chemical Granules.
This comprehensive data provides all the necessary information for a potential buyer on the Indian Business Portal, focusing on the machine's capabilities, specifications, and industry applications.
