The Suthar Pack Tech Auger Multi-Track Packaging Machine is an advanced high-speed automatic Form-Fill-Seal (FFS) solution engineered to fill and seal powdered, granulated, and non-free-flowing materials into multiple sachets simultaneously. Equipped with a precision servo-driven auger filling system, this machine offers exceptional dosing accuracy with minimal product variation, making it ideal for large-scale industrial packaging applications such as pharmaceuticals, food supplements, spices, and detergents. Available in configurations from 2 to 12 tracks, it maximizes throughput by producing multiple pouches per cycle, achieving speeds of up to 60 cycles per minute per lane. The machine suits a wide pouch capacity range from as low as 10 mg to 500 grams. Constructed from food-grade SS-304 stainless steel, it meets hygienic standards essential for contact with consumable goods. The integrated PLC control with HMI touch screen interface allows operators to manage recipes, monitor parameters, and adjust system settings intuitively, ensuring consistent and reliable packaging performance across diverse production environments.
Key Features
| Features | Description |
|---|---|
| Filling System | Precision Servo-Auger Filler |
| Material Suitability | Non-Free Flowing Powders, Fine Powders, Granules |
| Number of Tracks | Multi-lane configurable (2, 4, 6, 8, 12 lanes) |
| Maximum Speed | Up to 60 cycles per minute per track |
| Pouch Capacity Range | Highly adjustable, from 10 mg up to 500 grams |
| Filling Accuracy | ±0.5% to ±1% depending on product |
| Sealing Type | Four Side Seal (Standard), Center Seal (optional) |
| Control System | PLC-based with HMI touchscreen interface |
| Material of Construction | Food Grade Stainless Steel (SS-304) |
| Power Requirement | Three Phase (440 V AC), 8-10 KW power consumption |
| Attributes | Description |
|---|---|
| Machine Type | Auger Multi-Track Form-Fill-Seal Packaging Machine |
| Intended Use | Powder and Granule Sachet Packaging |
| Track Configurations | 2 to 12 lanes |
| Speed per Track | Up to 60 cycles/minute |
| Pouch Filling Range | 10 milligrams to 500 grams |
| Filling Method | Servo-driven auger volumetric filling |
| Sealing Styles | Four-side seal standard, center seal optional |
| Control Interface | PLC with color HMI touchscreen |
| Construction Material | SS-304 food-grade stainless steel |
| Electrical Requirement | Three phase, 440 V AC, 8-10 KW consumption |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
The machine is offered with multiple track configurations, supporting up to 12 lanes for simultaneous multi-pouch filling.
Yes, the machine accommodates a highly adjustable pouch capacity ranging from as low as 10 milligrams up to 500 grams per pouch.
It is specifically designed for non-free flowing powders, fine powders such as pharmaceutical and health supplements, as well as granulated products like spices, salt, sugar, and detergents.
The servo-driven auger filler provides filling accuracy typically within ±0.5% to ±1%, depending on the product being filled.
Yes, it supports four-side seal as the standard sealing type, with an option for center sealing depending on the model.
It incorporates a PLC-based control system with a user-friendly color HMI touchscreen interface for easy recipe management and real-time monitoring.
Yes, all product contact parts are made from food grade SS-304 stainless steel, ensuring compliance with hygiene and corrosion resistance requirements.
Country Of Origin: India
Feature
Specification
Filling System
Precision Servo-Auger Filler
Material Suitability
Non-Free Flowing Powders, Fine Powders, Granules
Number of Tracks
Multi-lane (e.g., 2, 4, 6, 8, 12 lanes)
Maximum Speed
Up to 60 cycles per minute (per track)
Pouch Capacity Range
Highly adjustable, ranging from small doses (e.g., 10 mg) up to 500 grams
Filling Accuracy
$\pm0.5\%$ to $\pm1\%$ (Product dependent)
Sealing Type
Four Side Seal (Standard), Center Seal (Model dependent)
Control System
PLC-based with HMI Touch Screen Interface
Material of Construction
Food Grade Stainless Steel (SS-304) for contact parts
Required Power
Three Phase (440 V AC), Power Consumption varies (e.g., 8–10 KW)
Auger Multi-Track Packaging Machine - High-Speed Powder Filling
Product Overview
The Suthar Pack Tech Auger Multi-Track Packaging Machine is a high-performance, automatic Form-Fill-Seal (FFS) solution designed for simultaneous filling and sealing of powdered, granulated, and non-free-flowing products into multiple sachets or pouches. Utilizing a precision Auger-based filling system, typically driven by advanced servo motors, this machine is engineered for exceptional accuracy, high throughput, and minimal product wastage, making it ideal for large-scale, high-volume production.
Key Features and Advantages
Multi-Track Efficiency: Available in configurations ranging from 2 to 12 tracks/lanes, the machine maximizes output by producing multiple pouches per cycle.
High Speed: Achieves production rates of up to 50–60 cycles per minute (PPM) per track. This translates to significantly high total output (e.g., thousands of pouches per hour), depending on the number of lanes and pouch length.
Servo-Driven Auger System: The core Auger filling mechanism is often servo-controlled, providing superior volumetric precision and consistency, crucial for expensive or fine powders. This ensures accurate dosing and maintains a low weight variation (typically $\pm0.5\%$ to $\pm1\%$).
Versatile Product Handling: Specifically designed for challenging materials, including:
Fine Powders: Pharmaceutical powders, health supplements, powdered coffee, milk powder, protein supplements.
Granules/Spices: Sugar, salt, spices, seasoning mixes, detergents.
User-Friendly Control: Controlled by a PLC (Programmable Logic Controller) system with a color Human-Machine Interface (HMI) touch screen, allowing for easy recipe management, parameter adjustment, and real-time monitoring.
Robust & Hygienic Construction: Built with durable materials, typically SS-304 Stainless Steel for all food contact parts and cladding, ensuring compliance with hygiene standards and offering excellent corrosion resistance.
Pouch Style Flexibility: Capable of producing various sachet styles, most commonly the Four-Side Seal pouch, often used for flat sachets.
