The LT Distribution Panel is a crucial electrical component designed to efficiently distribute low tension (below 1,000V) electrical power, typically at 415V or 230V, from transformers or generators to multiple loads in industrial, commercial, and residential settings. Engineered to ensure safe and reliable power distribution, this panel incorporates advanced features such as main incomers (MCCB/ACB/MCB), busbars, and multiple outgoing feeders equipped with circuit breakers like MCBs, MCCBs, ELCBs, and RCCBs. It offers comprehensive protection mechanisms including overload and short circuit protection, surge protection, and fault isolation, ensuring system safety and longevity. The built-in meters, indicators, and control switches allow for real-time monitoring of voltage, current, and power factor, facilitating efficient load management and operational control. Ideal for application in industrial plants, commercial buildings, hospitals, malls, hotels, and residential complexes, the LT Distribution Panel provides a reliable power management solution that complies with electrical safety standards and enhances the robustness of power systems in diverse environments.
Key Features
| Features | Description |
|---|---|
| Voltage Rating | Up to 1,000V, commonly 415V or 230V |
| Main Incomer | MCCB/ACB/MCB for controlling incoming power |
| Outgoing Feeders | MCBs, MCCBs, ELCBs, RCCBs for various load distribution |
| Protection Devices | Overload, short circuit, surge protection via breakers, fuses, and relays |
| Monitoring Instruments | Meters and indicators for voltage, current, and power factor monitoring |
| Load Management | Efficient distribution and overload prevention across multiple circuits |
| Safety Features | Fault isolation and electrical hazard prevention mechanisms |
| Applications | Industrial, commercial, residential, hospitals, malls, and hotels |
| Panel Construction | Robust enclosure with organized busbars and wiring for stable performance |
| Control Switches | Manual switching options for operational flexibility |
| Attributes | Description |
|---|---|
| Input Voltage | Up to 1,000V AC |
| Output Voltage | Typically 230V/415V AC |
| Rated Current | Customizable based on application requirements |
| Panel Material | Mild Steel / Stainless Steel Enclosure |
| Protection Level | IP42 or higher depending on model |
| Mounting Type | Floor-mounted or wall-mounted options available |
| Standards Compliance | IS/IEC Standards (e.g., IS 8623, IEC 60439) |
| Operating Temperature | -10°C to 55°C |
| Accessories | Optional surge protectors, meters, and relays |
| Customization | Panel layout and components tailored to customer specifications |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
The panel integrates circuit breakers such as MCCBs, MCBs, ELCBs, and RCCBs, along with fuses and surge protectors, providing comprehensive protection against overloads, short circuits, electrical faults, and surges.
Yes, the panel layout, rated current capacity, and component selection can be tailored to meet the specific power distribution requirements of different industrial, commercial, or residential applications.
It includes meters and indicators for real-time monitoring of voltage, current, and power factor, enabling effective load management and operational control.
By isolating faulty circuits promptly through protective devices and providing controlled and secure distribution of power, the panel minimizes electrical hazards and ensures safe power supply across residential units.
The panel is manufactured in compliance with IS and IEC standards, such as IS 8623 and IEC 60439, ensuring adherence to established safety and performance criteria.
Brand: magnum engineering
Country Of Origin: India
An LT Distribution Panel (Low Tension Distribution Panel) is an electrical panel used to distribute power from a transformer or generator to various loads at a lower voltage, typically below 1,000V (commonly 415V or 230V in industrial and commercial applications).
Key Functions of an LT Distribution Panel:
Power Distribution – Supplies electrical power to different circuits and machinery.
Load Management – Controls and distributes electricity efficiently to prevent overloading.
Protection – Includes circuit breakers, MCCBs, MCBs, fuses, and relays to protect against short circuits, overloads, and faults.
Monitoring & Control – Comes with meters, indicators, and control switches to monitor power usage and status.
Safety – Ensures electrical safety by isolating faulty circuits and preventing electrical hazards.
Components of an LT Distribution Panel:
Main Incomer (MCCB/ACB/MCB) – The main switch to control incoming power.
Busbars – Conductors distributing power across different circuits.
Outgoing Feeders (MCBs/MCCBs/ELCBs/RCCBs) – Distribute power to different loads.
Meters & Indicators – For voltage, current, and power factor monitoring.
Protection Devices – Surge protectors, fuses, and relays for safety.
Applications of LT Distribution Panels:
Industrial Plants – Power distribution for heavy machinery.
Commercial Buildings – Office power supply management.
Residential Complexes – Distributing power safely among flats or units.
Hospitals, Malls, & Hotels – Ensures uninterrupted power supply.
