Universal Drilling Fluids presents UNI-CBF Calcium Bromide Brine, a high-density clear brine fluid specially formulated for well workover and completion operations. This product has a base density of 14.2 lb/gal (1702 kg/m3) and can be adjusted within the 8.4 to 15.3 lb/gal (1007 to 1833 kg/m3) range to meet specific operational needs. UNI-CBF brine is compatible for blending with heavier brines for enhanced density requirements, including combining with sacked calcium chloride to achieve up to 15.3 lb/gal (1833 kg/m3), and zinc bromide brine for densities reaching 19.2 lb/gal (2301 kg/m3). It offers the flexibility of various crystallization points, enabling its application in diverse thermal conditions, including severe winter environments. The fluid’s clear brine nature ensures minimal formation damage and excellent wellbore stability, making UNI-CBF an ideal choice for rig operators focused on optimized drilling and completion efficiency. For best performance, gentle agitation is recommended during mixing to ensure complete dispersion.
Key Features
| Features | Description |
|---|---|
| Base Density | 14.2 lb/gal (1702 kg/m3) |
| Density Range | 8.4 to 15.3 lb/gal (1007 to 1833 kg/m3) adjustable |
| Compatibility | Blendable with calcium chloride and zinc bromide brines |
| Crystallization Points | Customizable for special and winter applications |
| Usage | Workover and completion fluid |
| Maximum Density Achievable | Up to 19.2 lb/gal (2301 kg/m3) when blended with zinc bromide brine |
| Mixing Instructions | Use gentle agitation for thorough dispersion |
| Form | Clear brine solution |
| Application | Suitable for high-density drilling and completion operations |
| Attributes | Description |
|---|---|
| Chemical Composition | Calcium Bromide (CaBr2) |
| Weight per Unit Volume | 14.2 lb/gal (1702 kg/m3) as stock |
| Density Adjustment Range | 8.4 to 15.3 lb/gal (1007 to 1833 kg/m3) |
| Mixing Compatibility | Compatible with sacked calcium chloride and zinc bromide brines |
| Maximum Density with Blends | Up to 19.2 lb/gal (2301 kg/m3) |
| Crystallization Point Customization | Available for special and winter use |
| Packing Unit | Sold per kilogram |
| Recommended Mixing Method | Gentle agitation |
| Applications | Workover fluid, completion fluid, and density adjustment in drilling operations |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
When blended with zinc bromide brine, UNI-CBF calcium bromide brine can achieve densities up to 19.2 lb/gal (2301 kg/m3). When blended with sacked calcium chloride, it can reach densities up to 15.3 lb/gal (1833 kg/m3).
Yes, UNI-CBF brines can be formulated with various crystallization points suitable for special applications including winter use to prevent crystallization at low temperatures.
It is recommended to use gentle agitation when mixing UNI-CBF brine to achieve thorough dispersion and consistent density.
The density range for UNI-CBF calcium bromide brine spans from 8.4 to 15.3 lb/gal (1007 to 1833 kg/m3), making it versatile for different workover and completion conditions.
Country Of Origin: India
