Ubiquiti NanoStation 5AC Loco

Inclusive of all taxes

The Ubiquiti NanoStation 5AC Loco is a compact and efficient outdoor wireless CPE designed for high-performance point-to-point and point-to-multipoint bridging and access applications. Featuring a sleek form factor measuring 179 x 77.5 x 59.1 mm and a lightweight of just 0.18 kg (6.35 oz), it is optimized for installation flexibility and ease of deployment. Powered by a robust MIPS 74K processor and equipped with 128 MB of memory, the NanoStation 5AC Loco ensures fast and reliable wireless connectivity. It delivers a high gain of 13 dBi for extended range and improved signal strength, supporting channel bandwidths from 10 MHz up to 80 MHz for versatile networking needs. The device includes a 10/100/1000 Mbps Ethernet port enabling high-speed network throughput. Easily monitor device status via power, Ethernet, and four-level signal strength LEDs. It uses passive Power over Ethernet (PoE) with pairs 4, 5+ and 7, 8 return, requiring a compliant 24V, 0.5A Gigabit PoE power supply (not included). With a maximum power consumption of 8.5W, it is energy efficient and well suited for business and industrial outdoor wireless network setups. This product is ideal for B2B buyers seeking a reliable, cost-effective, and high-performance 5 GHz wireless bridge or CPE solution.

Key Features

Features Description
Dimensions 179 x 77.5 x 59.1 mm (7.05 x 3.05 x 2.33 inches)
Weight 0.18 kg (6.35 oz)
Processor MIPS 74K
Memory 128 MB
Gain 13 dBi
Channel Bandwidth 10/20/30/40/50/60/80 MHz
Networking Interface 10/100/1000 Mbps Ethernet Port
LED Indicators Power, Ethernet, (4) Signal Strength
Power Method Passive PoE (Pairs 4, 5+; 7, 8 Return)
Power Supply 24V, 0.5A Gigabit PoE Supply (Not Included)
Max. Power Consumption 8.5W
Attributes Description
Frequency Band 5 GHz
Application Point-to-Point and Point-to-Multipoint Wireless Bridge
Antenna Type Integrated MIMO Antenna
Operating Temperature Insufficient Information
Weatherproofing Outdoor Use (Weather-Resistant)
Wireless Standards 802.11ac
Maximum Data Rate Insufficient Information
Mounting Options Pole Mount Support
Interfaces 1 x Gigabit Ethernet (RJ45)
Power Consumption Maximum 8.5 W
PoE Specification Passive PoE 24V, 0.5A
Weight 0.18 kg
Dimensions 179 x 77.5 x 59.1 mm

*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.

Be the first to write a review

Yes, the NanoStation 5AC Loco supports channel bandwidths up to 80 MHz, enabling higher throughput on the 5 GHz band.

No, the device requires a 24V, 0.5A Gigabit passive PoE power supply which is not included with the product.

It provides a single 10/100/1000 Mbps (Gigabit) Ethernet port for reliable wired connectivity.

Yes, the NanoStation 5AC Loco supports pole mounting, ideal for outdoor deployment.

The maximum power consumption of the NanoStation 5AC Loco is 8.5 watts, making it energy efficient for outdoor installations.

  • Incorporation Type

  • GST

  • GST Registration Date

  • Number of Employees

  • Import Export Code (IEC)

  • Year of Establishment

  • Nature of Business

  • GlobalLinker Member Since

NanoStation 5AC Loco
Dimensions 179 x 77.5 x 59.1 mm (7.05 x 3.05 x 2.33"),
Weight 0.18 kg (6.35 oz),
Processor MIPS 74K,
Memory 128 MB,
Gain 13 dBi,
Channel Bandwidth 10/20/30/40/50/60/80 MHz,
Networking Interface 10/100/1000 Mbps Ethernet Port,
LEDs Power, Ethernet, (4) Signal Strength,
Power Method Passive PoE (Pairs 4, 5+; 7, 8 Return),
Power Supply 24V, 0.5A Gigabit PoE Supply (Not Included),
Max. Power Consumption 8.5W,
