The all new BS-C101 Star is the fastest scanner in this segment and is loaded with features. It represents high-durability and faster customer checkouts, with an unbeatable first read scan success rate. It’s highly functional and is a great business companion.

ADVANTAGES :

• Fastest in this segment with 330 scans per second
• Increased resolution of 2500 pixels
• Greater decoding accuracy
• Auto-scan mode enables hands-free operation
• Higher depth-of-field up to 300 mm enables decoding from longer distances
• Plug & Play - Easy to Install

SPECIFICATIONS

Light Source

650 nm visible laser diode VLD

MPU

32 bit

Depth of Field

35 200 mm UPC/EAN 100%, PCS=90%

Scan Rate

330 scans per second

Scan Angle

52°

Pitch / Roll / Skew angle

65° / 30° / 65°

Minimum Bar Width

4 mil @ PCS=90% Code 39

Print Contrast

30% @ UPC/EAN 100%

Indicators LED

Three colour LED green, red & blue

Beeper Option

Programmable tone & beep time

System Interfaces

Keyboard, RS232C, HID USB, wand

Physical Dimensions

L106.7 x D58.0 x H155.0 mm device only

Weight

148 g stand excluded

Cable

Standard 2.0M straight

Input Voltage

5 VDC ±10%

Power Consumption

1.0 watts

Operating Current

200 mA

Laser Class

CDRH Class Iia: IEC 608251: Class 1

EMC

CE & FCC DOC compliance, VCCI, BSMI

Operating Temperature

0°C – 40°C, 32°F – 104°F

Storage Temperature

20°C – 60°C, 4°F – 140°F

Operating Humidity

5% – 95% RH noncondensing

Light Levels

4,500 Lux fluorescence

Drop Durability

Designed to withstand 1.0 M drops

Barcode

Most popular 1D barcodes, incl. GS1 DataBar & PDF 417
