The Supreme-3Fan Specific Gravity Separator is an advanced machine designed specifically for the separation and grading of granular materials and seeds based on their specific weight. Ideal for processing various seeds, spices, and grains, this machine excels at removing impurities, ensuring top-grade product quality. With a capacity of 1-2 tons per hour, it showcases a dynamic balance and is equipped with three powerful fans, ensuring optimal performance and efficiency. The variable oscillation speed and adjustable deck inclination enhance its versatility, allowing users to customize settings according to the specific requirements of their processing needs. The elevator feed system ensures a smooth material input, while the compact dimensions of 2170mm x 1100mm x 1370mm make it suitable for a variety of operational spaces. Whether for large-scale agricultural businesses or smaller seed processing facilities, the Supreme-3Fan delivers consistent and superior results in seed separation.
Key Features
| Features | Description |
|---|---|
| Model | SUPREME-3FAN |
| Capacity | 1-2 TP |
| Number of Fans | 3 |
| Electric Motor Power | 3+1.5 HP, 440 volt, 3ph, 50hz, AC supply |
| Deck Size | 800mm x 1600mm (LxW) |
| Deck Area | 1.28 m² |
| Oscillation Speed of Deck | Variable |
| Deck Inclination | Variable |
| Feed System | Elevator |
| Overall Dimensions | 2170mm x 1100mm x 1370mm (LxWxH) |
| Attributes | Description |
|---|---|
| Processing Type | Specific Gravity Separation |
| Suitable For | Various Seeds, Spices, Grains |
| Impedance to Impurities | High |
| Weight Separation Performance | Separates seeds of the same size but different weights |
| Construction Material | Heavy-duty steel frame |
| Maintenance Requirement | Low |
| Operational Environment | Indoor or covered areas |
| Ease of Operation | User-friendly controls and setup |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
The Supreme-3Fan can process a variety of free-flowing granular materials including all types of seeds, spices, and grains.
The Supreme-3Fan has a maximum capacity of 1-2 tons per hour.
This machine utilizes the principle of specific weight separation, allowing it to effectively sort seeds of the same size but different weights, thus achieving high accuracy in grading.
Yes, the Supreme-3Fan is designed for user-friendly operations with adjustable settings for both deck inclination and oscillation speed.
The overall dimensions of the machine are 2170mm in length, 1100mm in width, and 1370mm in height.
Model SUPREME-3FAN
Capacity 1-2TPH
"Dynamically balanced
No. of Fan" 3 Fan
Electric Motar 3+1.5 HP, 440 volt,3ph, 50hz,Ac supply
Deck Size (mm) 800x1600 (LxWxH)
Deck area (m²) 1.28
Oscillation speed of deck Variable
Deck Inclination Variable
feed System ELEVATOR
Overall Diamm 2170x1100x1370 (LxWxH)
