The 3118 Protektor-UV PCB Conformal Coating Liquid is designed specifically for protecting printed circuit boards (PCBs) in a variety of industries from harsh environmental conditions. This advanced fast-drying acrylic lacquer provides exceptional insulation and safeguarding against moisture, corrosion, dirt, dust, fungus, and caustic vapors, ensuring longevity and reliability of your electronic components. With a lovely clear and transparent finish, this product offers high dielectric strength to prevent arcing and the corona effect. What truly sets the 3118 Protektor-UV apart is its UV traceability feature, allowing for easy inspection of the coating's integrity post-application. Conforming to IPC-830CC and MIL-I-46058C specifications, along with RoHS compliance, it guarantees not only performance but also environmental safety. This product's shelf life of 18 months and broad temperature resistance make it the ideal choice for B2B customers dedicated to quality and sustainability in their operations.
Key Features
| Features | Description |
|---|---|
| Type | Acrylic Resin (AR) |
| Appearance | Clear Transparent |
| Specific Gravity | 0.95 |
| Dry to Touch Time | 30 Mins |
| Film Thickness | 26 Micron |
| Insulation Resistance | 2.5 X 10^11 Ohms |
| Breakdown Voltage | 700 V at 26 Micron |
| Temperature Resistance | -70°C to 120°C |
| Shelf Life | 18 Months |
| Attributes | Description |
|---|---|
| Compliance | IPC-CC-830C, MIL-I-46058C, RoHS compliant |
| UV Traceability | Yes |
| CFC Propellant | Non-CFC, Flammable |
| Environmental Approval | Approved by Centre for Development of Telematics (C-DOT) |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
The 3118 Protektor-UV protects PCBs from moisture, corrosion, dirt, dust, fungus, and caustic vapors.
Yes, the 3118 Protektor-UV has UV traceability, allowing easy inspection of the coating's integrity after application.
The coating is effective within a temperature range of -70°C to 120°C.
The shelf life of this conformal coating is 18 months.
Yes, the product is RoHS compliant and approved by the Centre for Development of Telematics (C-DOT), ensuring its environmental safety.
UV Tracable Conformal Coating - Protektor® is a fast drying single component acrylic lacquer for PCBs to protect them from harsh environments, moisture, corrosion, dirt & dust, fungus, caustic vapors, etc.
The high dielectric strength prevents the component from high voltage arcing and corona effect while the coating further protects and insulates the electrical and electronic components. This variant comes with UV based Inspection ability
It conforms to IPC-830CC-Military Grade MIL-I-46058C specification, is approved by Centre for Development of Telematics (C-DOT) and is RoHS compliant and environment friendly.
Insulation Resistance after Chamber Test: 2.5 X 1011 Ohms
Breakdown Voltage: 700 V at 26 Micron
Type: Acrylic Resin (AR)
Appearance: Clear Transparent
Specific Gravity: 0.95
Propellent: Non CFC, Flammable
Temperature Resistance: -70o C to 120o C
Dry to Touch Time: 30 Mins
Film Thickness: 26 Micron
Clarity: Clear transparent
Shelf Life: 18 Months
GRADE: IPC-CC-830C
It conforms to IPC-830CC-Military Grade MIL-I-46058C specification, is approved by Centre for Development of Telematics (C-DOT) and is RoHS compliant and environment friendly.
