RACE CABLES PRIVATE LIMITED

Control Cables are designed for control, monitoring, and signaling applications in industrial plants, power stations, machinery, automation systems, and infrastructure projects.

These cables are manufactured using stranded annealed bare copper conductors and are available in PVC or XLPE insulation, suitable for 1100 Volts grade operations. Offered in both armoured and unarmoured constructions, they ensure excellent mechanical protection, electrical reliability, and long service life.

CONSTRUCTION DETAILS

• Conductor: Stranded Annealed Bare Copper

• Insulation: PVC / XLPE

• Core Type: Single Core / Multi Core

• Inner Sheath: PVC

• Armouring:

  • G.I. Wire Armoured / G.I. Strip Armoured

  • Also available in Unarmoured construction

• Outer Sheath: PVC

• Voltage Grade: Up to 1100 Volts




  HSN code - 85444999

Co-Axial Cables are engineered for high-quality signal transmission in broadcasting, CCTV, satellite, telecommunications, and data communication applications.

Manufactured with solid or stranded copper conductors, these cables are insulated with Polyethylene (PE) for stable signal performance and minimal interference.

Available in braided, armoured or unarmoured constructions with overall PVC sheath, these cables offer excellent mechanical protection and durability.

Key Features:

• Conductor: Solid or Stranded Copper

• Insulation: PE (Polyethylene)

• Braiding: Copper Braided Shield for signal protection

• Construction: Armoured or Unarmoured

• Outer Sheath: PVC for mechanical and environmental protection

• Popular Types: RG-59U, RG-6, RG-11

• Customer-specific specifications available

• Core Size: 16 / 20 AWG, up to 24 pairs




  HSN Code- 85444999

Submersible Cables are specially designed for submersible pumps, borewells, and water supply systems. They are manufactured using flexible annealed bare copper conductors, insulated and sheathed with PVC, ensuring high durability and excellent conductivity.

Available in round and flat types, these cables feature high tensile strength to withstand mechanical stress during installation and operation. Compliant with IS 694 and BS 6004, they are also manufactured as per customer specifications for project-specific requirements.

Key Features:

• Flexible annealed bare copper conductors

• PVC insulated and sheathed for long life in wet conditions

• Available in Round and Flat cable types

• High tensile strength for mechanical robustness

• Suitable for submersible pumps, irrigation, and water supply applications




  TECHNICAL DETAILS / CONSTRUCTION

• Conductor: Flexible Annealed Bare Copper

• Insulation / Sheath: PVC

• Construction: Round or Flat

•

• HSN Code- 85444999

Instrumentation Cables manufactured for reliable transmission of signals in industrial control, process automation, load cell, serial communication and MODBUS applications. These cables are designed for stable performance in electrically noisy and harsh industrial environments.

The cables are manufactured with stranded / flexible annealed bare or tinned copper conductors, insulated with PVC or Polyethylene (PE). Insulated cores are twisted together to form pairs or triads to reduce electromagnetic interference.

Shielding options include Aluminium Mylar Tape, Copper Tape or Copper Braiding, providing excellent protection against external electrical noise. Cables are available in armoured (wire / strip) as well as unarmoured constructions, with an overall PVC sheath for mechanical and environmental protection.

Construction & Technical Details

• Voltage Grade: 600 / 1100 Volts

• Conductor: Stranded / Flexible Annealed Bare or Tinned Copper

• Insulation: PVC / Polyethylene (PE)

• Core Formation: Pairs / Triads

• Shielding: Aluminium Mylar / Copper Tape / Copper Braided

• Armouring: Wire / Strip Armoured or Unarmoured

• Outer Sheath: PVC




  HSN Code - 85444999

CAT5, CAT6 and RS-485 Ethernet Cables are designed for high-speed data transmission, industrial networking, automation systems, and communication applications. These cables ensure reliable performance, low signal loss, and excellent protection against electromagnetic interference.

Manufactured using solid copper conductors, with PE insulation and twisted pair construction, these cables are available in UTP, STP, and FTP configurations, suitable for both armoured and unarmoured installations.

CONSTRUCTION DETAILS

• Conductor: Solid Bare Copper

• Insulation: PE (Polyethylene)

• Core Formation: Twisted Pair

• Cable Type:

  • UTP (Unshielded Twisted Pair)

  • STP (Shielded Twisted Pair)

  • FTP (Foiled Twisted Pair)

• Armouring: Armoured / Unarmoured

• Outer Sheath: PVC
